Help Center600L/H Waste Oil Recycling Plant, Transformer Oil Refinery/Oil Filtration Machine
Related Products
-
Enclose Oil Filtration Machine, Used Oil Recycling Plant for Insulation OilUS$ 7500 - 50000MOQ: 1 Piece -
Wheels Type Oil Filtration Machine, Waste Oil Recycling Plant for Turbine OilUS$ 3500 - 20000MOQ: 1 Piece
-
Waste Engine Oil Recycling Machine, Black Oil Distillation PlantUS$ 20000 - 60000MOQ: 1 Piece
-
Waste Oil Recycling Plant, Used Engine Oil to Diesel Distillation MachineUS$ 5000 - 20000MOQ: 1 Piece
-
Waste Oil Purification Machine, Oil Filtration System, Oil Recycling for ImpurityUS$ 1500 - 5000MOQ: 1 Piece
Application:
This machine is special for purifying various of insulating oils including unqualified transformer oil, mutual inductor oil and circuit breaker oil etc. It is widely applied to areas of power station, transformer substation, railway, petroleum, chemical and metallurgy. Also it is the best choice for filling oil into power equipment and drying moisture of power equipment.
Features:
1.This machine is small, hi-efficient, convenient. And it can be operated with electrical, vacuum filling oil into the power equipment and drying moisture of power equipment.
2. Distinctive remove-impurity technology,which filters the impurity through double FH trapezoidal network and absorbing by high polymer without the mechanical power.
3.Bi-infrared liquid Duplex 3D evaporation technology, dewatering and degassing very effectively.
4.Any insulating oil can be treated on-line at the working site
Advantages:
This machine adopts an high effective vacuum and the internationally advanced stereo-evaporation technology, which enable highly effective removal of water, gas and impurities without cutting off power, shutdown of machine and change of oil, which allows transformers running as energized.
Parameters Data
Item |
Unit |
ZY-20 |
ZY-30 |
ZY-50 |
ZY-100 |
ZY-150 |
ZY-200 |
Flow Rate |
L/min |
20 |
30 |
50 |
100 |
150 |
200 |
Vacuum Degree |
MPa |
-0.08 ～-0.095 |
|||||
Working Pressure |
MPa |
≤0.3 |
≤0.5 |
||||
Temperature Range |
℃ |
10 ～80 |
|||||
Power Supply |
380V, 3PHASE, 50HZ (Or as needed) |
||||||
Working Noise |
dB(A) |
≤75 |
≤75 |
≤75 |
≤80 |
≤80 |
≤80 |
Heating Power |
kW |
18 |
24 |
30 |
45 |
60 |
72 |
Total Power |
kW |
22 |
28 |
35 |
50 |
68 |
80 |
Inlet (outlet) caliber |
mm |
25 |
25 |
32 |
42 |
50 |
50 |
Dimension |
mm |
1500×900×1550 |
1600×900×1650 |
1600×900×1700 |
1600×950×1700 |
1600×950×1800 |
1700×1000×1900 |
Weight |
Kg |
400 |
450 |
600 |
800 |
850 |
900 |
Breakdown Voltage |
kV |
≥70 |
|||||
Water Content |
PPM |
≤5 |
|||||
Gas Content |
% |
≤0.1 |
|||||
Particles Size |
μm |
≤1~5(Without Free Carbon) |
|||||
Cleanliness ≤NAS 1638 Grade 6 | |||||||
