10 bar 16 bar 3 ton Diesel oil steam boiler
3 ton diesel oil fired boiler Advantages:
1. Large volume combustion chamber
2. Imported combustion machine
3. High thermal efficiency, stable output, strong load adaptability
3 ton Industrial Steam Boiler WNS3-1.25-Q(Y)
WNS Series Steam Boiler Technology Parameter Table Boiler model
Rated
capacityRating
pressureFeed
temperatureSteam
temperatureActive grate area Thermal
efficiencyWeight Dimensions Light oil
Heavy oil Natural gas Liquid gas City gas t/h MPa ℃ ℃ Kg/h Kg/h m3/h m3/h m3/h %
Ton mm WNS1-1.0-Y(Q)
1 1 20 184 65.5 67.3 84.2 29 176 91 4.3 3561×1690×1910 WNS 2-1.25- Y(Q)
2 1.25 20 194 129.6 132.2 165 57.3 346 92 7.2 4111×1950×2199 WNS3-1.25-Y(Q)
3 1.25 20 194 192 195 250 82 510 92.1 8 4330×2248×2564 WNS4-1.25- Y(Q)
4 1.25 20 194 256 261.9 323.6 109 682 93 9.6 4732×2150×2448 WNS5-1.25- Y(Q)
5 1.25 20 194 318 322 386 140 87 93 12.5 5970×2360×2796 WNS6-1.25- Y(Q)
6 1.25 20 194 380 390.6 450 164 1020 93.2 16.5 5500×2600×2990 WNS8-1.25- Y(Q)
8 1.25 105 194 503 517 642 209 1321 93.5 24.8 6450×2800×3200 WNS10-1.25- Y(Q)
10 1.25 105 194 628 643 805 264 1654 93.5 26.8 6800×2900×3394 WNS15-1.25- Y(Q)
15 1.25 105 194 940 965 1182 400 2417 93.5 38 7150×3200×3540 WNS20-1.25- Y(Q)
20 1.25 105 194 1250 1301 1597 520 3299 93.5 55 8200×3400×3826
Safety:
It adopts wet back & three -pass structure which ensures boiler safe operation and extend service life.
High Efficiency:
Boiler equips Energy Saver which can improve boiler thermal efficiency more than 2~3% & decrease the temperature of exhaust smoke.Steam boiler work efficiency is more than 93%.
Environmental Protection:
Boiler equips European Burner, fuel combustion can achieve automatic adjustment to save energy, also decrease the dust emission & SO2 emission & NOx emission.
Control:
Boiler is equipped with advanced automatic control system, automatic adjustment setting pressure boiler operation.
Our Service
1.Any products quality problems manufactured and sold by our company ,our company will execute "Three Contract "service, our sales service three contract team will be in charge of this job.
2.The minute we received products quality information from our customers(by means of call, mail or oral notice),we will dispatch related staff to settle the problem on site at once.
3.After sale service staff must settle related quality problem carefully, considerately, guarantee clients timely use without further worry.
10 bar 3 ton Diesel Oil fired steam boiler for milk processing line
