Trolley Color Doppler Ultrasound Scanner System (YJ-U300t)

Name: Trolley Color Doppler Ultrasound Scanner System (YJ-U300t)
Brand: Forever Medical
SKU: 157244196
Availability: InStock

US$ 4698 - 8000 MOQ: 1 Unit

Key Specifications

Brand Name:

Forever Medical

Place of Origin:

China

Model Number:

YJ-U300t

Zhengzhou Medbes International Trading CO., LTD.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

20 days

Brand Name Forever Medical

Place of Origin China

Model Number YJ-U300t

Type Doppler Ultrasound Equipment

Full-digital Trolley Color Doppler Ultrasound Scanner (YJ-U300T A/B)

Standard Configuration
	Main unit
	15inch LCD Monitor
	Windows xp system and 64G hard disk
	Convex array probe and one more probe
	English User Manual
	B,2B,4B, B/M, M, B/C display mode
	Print/video/VGA/2 USB ports
	Color doppler, THI, Itouch, PW, CMF,B/C mode
	18 months After-sale Warranty Three probe connectors
Optional Items
Description
Linear array probe ：**USD
Micro-convex(Cardiac) array probe ：**USD
Trans-vaginal probe ：**USD
Rectal array probe ：**USD
Printer ：**USD

Optional Picture …………………………………………………………………………………

Model	ATNL6800 Trolley Color Doppler
Display mode	B&W mode: B, 2B, 4B, B/M, M,B/C Color Doppler mode: CFM, PDI, PW Duplex: Real-time simultaneous 2D, Doppler Gray scale: 256 Display: 15 inches LCD monitor Transducer frequency: 2.5-10 MHz Digital technology: Dynamic Receiving Focusing (DRF) Dynamic Frequency Scanning (DFS) Scanning depth: 300mm
Main Technical Specification:	Imaging Processing Pre-processing: 8-segment TGC Preset Gain (B&W, Color, Doppler) Audio PRF Dynamic Range Image enhancement Acoustic Power Post-processing: Gray map Black/white reverse Left/right reverse Up/down reverse Functions: Cine-loop: 1000 frame cine loop memory Storage media: 64G massive image-storage capacity Zoom: Pan Zoom USB ports: 2 THI: tissue harmonic imaging ITouch IClear Imaging
Measurement:	B mode: distance, circumference, area, volume, angle, fetal growth, cruve M mode: distance, time, velocity, heart rate Software package: abdomen, gynecology, obstetrics, cardiology, small parts, urology Doppler Mode: Vs, Vd, RI, PI, SD
