Car Wheel Lateral/Radial Run Out Measuring Machine (Production Line Type)

It is used for Used for measuring the raidial and lateral run-out of passenger car wheel, which is capable of doing first and multiple harmonic wave calculation function.
Structure: Horizontal machine frame, it consists of wheel lifting, wheel measuring, and qualified wheel classificaiton conveying belt etc.
Wheel Diameter: 13″ ~ 18″
Wheel Width: 3.5″ ~ 8″
Disc offset:  0mm ~ 80mm
Measuring rhythm: 4 ~ 5 PCS/min
Wheel positioning means: Center hole (expanding mandrel)+mounting face
Detection means: laser non-contact measurement,
                               not affected by wheel color difference
Motor Power: 5.0 kW
Dimension: Approx. L5200mm×W2300mm×H2600mm
Total Weight: Approx. 6t
