Home > Electrical & Electronics > Passive Components > Capacitor > Two POTS Port GPON Optical Network Terminal Fiber To The Premises GN2000-04GS
Two POTS Port GPON Optical Network Terminal Fiber To The Premises GN2000-04GS
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
GCOM
Place of Origin:
China
Model Number:
GN2000-04GS
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
4 Ethernet LAN Port Optical Network Termination 4 Port GPON ONT GN2000-04GNegotiableMOQ: 1 Piece -
4 Data Ports GPON Optical Network Terminal +0.5-+5 DBm Optical Output GN2000-04GS-2VWNegotiableMOQ: 1 Piece
-
ITU-T G.984 1 Port GPON ONU With 10/100/1000Base-T Data Interface GN2000-01GNegotiableMOQ: 1 Kilogram
-
FTTx User Terminal Data-type EPON ONU With 1*EPON Port+4*Ethernet Port EN2000-04SNegotiableMOQ: 1 Piece
-
IEEE 802.3ah EPON FTTx OLT Pizzabox 4 PON Port+ 4 10GE SFP+ EL5610-04PNegotiableMOQ: 1 Piece
Brand Name
GCOM
Place of Origin
China
Model Number
GN2000-04GS
Delivery Time:15 working days
Certification:CE, FC, UL, CCC
Product
GN2000-04GS-2VT
Port
1 GPON interface
4 Ethernet LAN port(10/100/1000 Base-T
Dimension(L×W×H)
228mm x176mmx 41mm (Wx D x H, without bracket)
228mm x176mmx 49mm (W x D x H, with bracket)
Weight
0.7 KG excluding power adaptor
+12V (feed via external AC/DC adapter)
8-PIN power input with UPS monitoring and 2-PIN power adaptor input
Dying Gasp support
Power switch
Power consumption:less than 12.5W
Max power consumption
<12.5W
Temperature: 0℃ ~ 40℃
Humidity: 5% ~ 95% relative humidity
Compliant with ITU-T G.984 GPON standards
SFF type laser, SC/APC connector
1.244Gbps Burst Mode Upstream Transmitter
2.488 Gbps Downstream Receiver
Compliant with ITU-T G.984.2 Amd1, Class B+
10/100/1000 Base-T interface with RJ-45 connectors
Ethernet port auto negotiation or manual configuration
MDI/MDIX automatically sense
Hardware priority queues on the downstream direction in support of CoS
802.1D bridging
VLAN tagging/detagging per Ethernet port
VLAN stacking (Q-in-Q) and VLAN Translation
IP ToS/DSCP to 802.1p mapping
Class of Service based on UNI, VLAN-ID, 802.1p bit, and combination
Marking/remarking of 802.1p
IGMP v2/v3 snooping and IGMP snooping with proxy report
Broadcast/Multicast rate limiting
Multiple WAN interfaces supporting
WAN connection
Certification:CE, FC, UL, CCC
Two POTS Port GPON Optical Network Terminal Fiber To The Premises GN2000-04GS
Overview:
To deliver triple-play services to the subscriber in Fiber-to-the-Home or Fiber-to-the-Premises application, the GPON RGU (Residential Gateway Unit) GN2000-04GS-2VT incorporates interoperability, key customers’ specific requirements and cost-efficiency.
Equipped with ITU-T G.984 compliant 2.5G Downstream and 1.25G Upstream GPON interface, GN2000-04GS-2VT supports the full Triple Play of services including voice, video, and high speed internet access service.
Compliant with standard OMCI definition, GN2000-04GS-2VT is manageable at remote side and supports the fullrange FCAPS functions including supervision, monitoring and maintenance.
Product Specification:
|
Item |
Specification |
|
|---|---|---|
auto-sensing)
2 POTS Interface 1 RF Video InterfacePower Supply
Working Environment
GPON Interface
1. 0.5dBm ~+5dBm launch power, -27dBm sensitivity, and -8dBm overload
Wavelengths:1. US 1310nm, DS 1490nm
Laser compliant with FCC 47 CFR Part 15, Class B, and FDA 21 CFR 1040.10 and 1040.11, Class I, ONT support Class C or Class C+ optics as an option Support G.984.5 Blocking Filter as an option Multiple T-CONTs per device Multiple GEM Ports per device Flexible mapping between GEM Ports and T-CONT Activation with automatic discovered SN and password in conformance with ITU-T G.984.3 AES-128 Decryption with key generation and switching FEC (Forward Error Correction) in both directions DBA reporting by piggyback reports in the DBRu (mode 0 and mode 1) 802.1p mapper service profile on U/S Mapping of GEM Ports into a T-CONT with priority queues based scheduling Support Multicast GEM port and incidental broadcast GEM portEthernet Interface
Gateway Features
1. Point-to-Point Protocol over Ethernet (PPPoE)
2. Dynamic Host Configuration Protocol (DHCP)
3. Static
DHCP server for LAN devices DNS relay Network Address Translation (NAT) / Network Address Port Translation (NAPT) Port forwarding Static routing Traffic classification and QoS based on Layer 3 and Layer 4 Identifier Access Control List (ACL) VPN Pass thru for Point to Point Tunneling Protocol (PPTP), Layer 2 Tunneling Protocol (L2TP) and IP Security Protocol (IPSec) Firewall Application Layer Gateway (ALG) Demilitarized Zone (DMZ) Dynamic Domain Name Server (DDNS) Network Time Protocol (NTP) Universal Plug and Play (uPnP) IGMP proxy IPv61. Stateless Address Autoconfiguration(SLAAC)
2. DHCPv6
3. PPPoEv6
4. DNSv6
