96 core dome type Fiber Optic Closure / 3C-FOSC-8-1 PC material waterproof
- T/T L/C D/P D/A
- 7 days
You May Like
-
Plug And Play Fast Ethernet Media Converter , Fiber Optic Ethernet Switch Flow Control Capabilities
-
Multipexer Single Fiber DWDM MUX DEMUX 40 Channles With Higt Density DWDM Chassis
-
Multiplexer Fast Ethernet SFP Fiber Optic Media Converter Full Duplex And Half Duplex
-
Poled Mounted Fiber Terminal Box , ABS / PC Material Cable FTTH Termination Box For CATV Networks
-
Optional Forward Fragments Fiber Optic Media Converter 10/100M UTP Ports Expands The Size Of An Exis
-
Up To 96 cores Dome Type Fiber Optic Closure / 3C-FOSC-08-2 fiber optical splice closure
Product Details
| Brand Name | 3c-link | Place of Origin | China | |
| Model Number | 3C-FOSC-8-1 |
Product Description
Certification:CE ISO9001
96 core dome type Fiber Optic Closure / 3C-FOSC-8-1 Fiber Splice Enclosure
Description:
The use of high-strength engineering plastic shell that can endure harsh conditions such as vibration, impact, tensile
cable distortion and strong temperature changes
The use of reusable components to open seal in order to ensure a good airtight waterproof performance.
Does not require special tools, easy to install and open the duplicate.
The scope of application : aerial, direct-buried, wall-mounting, duct-mounting.
Features:
• Up-down bisection, horizontal type
• 2 inlet/outlet
• 96 cores max capacity
• Slide-in-lock design, over 90 opening angle tray
• Elastic integrated seal ensure tightening fit
• Housing provide fire resistant, waterproof, and quakeproof for splices while handing
• Operating Temperature: -40 ~ +65 °C
Applications:
Widely used in aerial, duct places outdoor and can be directly buried underground.
| product outlook size | 410*140(Diameter) |
| Product material quality | PC(Polycarbonate) |
| Product weight | Approximately2.6kg |
| Suitable Dia of cable | 8-20mm |
| Fibers/Tray | 24 |
| Max capacity(F) | 96 in two layers |
| Outside box size | 44*22*64 |
| Each packing quantity | 9 pieces |
Tag:fiber optical splice closure, fiber optical joint box, fiber optical splice enclosure
