Help CenterHigh Precision ABS Material Fiber Optic PLC Splitter Large Operating Temperature Range
Related Products
-
Fused Biconic Taper Fiber Optic Coupler Splitter Cable Length / Diameter OptionalNegotiableMOQ: 1 Piece -
19 Rack Mount Passive Fiber Optic PLC Splitter 2 mm or 3 mm PigtailsNegotiableMOQ: 1 Piece
-
Intelligent 1:32 Rack Type Fiber Optic PLC Splitter 1U Black AL High Channel CountsNegotiableMOQ: 1 Piece
-
Custom Planar Lightwave Circuit Splitter , ROHS PLC Splitter Module Low PDL Compact DesignNegotiableMOQ: 1 Piece
-
2 Ports Mini FTTH Terminal Box Fiber Outlet With 0.9mm / 2.0mm / 3.0mm Optical CableNegotiableMOQ: 1 Piece
Certification:CE ISO9001
1 x N / 2 x N ABS Type Fiber Optic PLC Splitter , G.657A or Customized fiber type , 1260 to 1610 wavelength
PLC stands for Planar Lightwave Circuit, PLC splitters are used to distribute or combine optical signals.It is based on planar lightwave circuit technology and provides a low cost light distribution solution with small form factor and high reliability . It owns the features of compact size, broad operating wavelength, high reliability and good uniform power splitting.Optical splitter is generally deployed in passive optical network(EPON, BPON GPON ), giving carriers the ability to split optical signals to multiple customer premises, enabling the connection of multiple branch optical fibers in case that one trunk optical fiber was applied.
3C-LINK offers the PLC splitters including 1×N to 64 and 2×N to 64 types, they are with a wide range of working wavelength from 1260nm to 1620nm.They feature compact size and very good optical performance.19"rack-mounted PLC Splitter series are designed for installing in standard communication cabinet.Installation space is more compa ct,1:4,1:8,1:16,1:32,2:4,2:8,2:16,2:32 devices are 1U height,1:64 for 2U height.3C-LINK also can supply PLC Splitter suitable for various occasions on customer requests. All the 3C-LINK ’s products confirm in the standard of telcordia GR-1221 and GR-1209, also pass SGS Product Certification.
3C-LINK’s 1 x N/ 2 x N PLC Splitter features guaranteed performance specifications and high reliability that surpass Telcordia requirements and is tailored for different applications and markets.
Our optical fiber array and PLC chip are precisely aligned within an ultra compact package and tested according to industry standard test procedures,100% Temperature Cycle Testing from -40 to +85 centigrade.
Features
Low Insertion loss Low Return loss High Reliability Low PDL High Precision High Stability Strong metal construction,Compact designHigh channel counts
Uniform Power Splitting Wide wavelength rangeLarge operating temperature range
Customized packaging and configuration,Multiple fiber cable inputs
Excellent Environmental & Mechanical Stability
Telcordia GR-1209 & GR-1221 compliant
Telcordia GR-326 compliant
Applications
CATV Telecommunication G/EPON Networks WAN Networks Metro Networks Data Networks Test SystemSpecifications
| SPECIFICATION | 1*2 | 2*2 | 1*4 | 2*4 | 1*8 | 2*8 | 1*16 | 2*16 | 1*32 | 2*32 | 1*64 | 2*64 |
| Insertions Loss (dB) | 3.8 | 4.0 | 7.1 | 7.6 | 10.2 | 11.0 | 13.5 | 14.4 | 16.5 | 17.5 | 20.5 | 21.0 |
| Uniformity(dB)(Max) | 0.4 | 0.6 | 0.6 | 0.8 | 0.8 | 1.5 | 1.2 | 2.0 | 1.5 | 2.5 | 2.5 | 2.5 |
| Return Loss | >55dB For APC and >50dB For UPC | |||||||||||
| Directivity(dB) | >55dB | |||||||||||
| Operating Temperature | -40 to +85℃ | |||||||||||
| Wavelength(nm) | 1260 to 1610 | |||||||||||
| Fiber Type | G.657A or Customized | |||||||||||
| Dimensions(mm) | 100*80*10 | 120*80*18 | 140*115*18 | |||||||||
Products show
