Home > Products > Geosynthetics > Cheaper Price HDPE Liner
Cheaper Price HDPE Liner
- 100000 Square Meter / Square Meters per Month
- Qingdao
- T/T
- 8m wide 140m long 1.5mm thick GRIGM13 HDPE geomembrane smooth surface
- 8m wide 200m long 1.0mm thick GRIGM13 HDPE geomembrane smooth surface
- 8m wide 100m long 2.0mm thick GRIGM13 HDPE geomembrane smooth surface
- 7m wide 100m long 2.0mm thick GRIGM13 HDPE geomembrane smooth surface
- 7m wide 140m long 1.5mm thick GRIGM13 HDPE geomembrane smooth surface
- 7m wide 200m long 1.0mm thick GRIGM13 HDPE geomembrane smooth surface
Product Details
Place of Origin: | Shandong, China | Brand Name: | Lihe | Model Number: | G001 |
Material: | HDPE |
Product Description
Specifications
Cheaper Price HDPE Liner:Chemical resistance and UV resistance
Punture resistance
On-time delivery
Cheaper Price HDPE Liner
Description
HDPE Geomembrane is made from High density Polyethylene (HDPE) resins by the coextrusion Blowing Molding process resulting in a high quality flexible Geomembrane which is impermeable in nature.
A critical element in the proper functioning of a landfill containment system is the liner(s). The use of geomembranes on the bottom and sides of a landfill as an integrated leachate collection system and a leak detection system has been considered necessary for many years. High Density Polyethylene geomembrane, resistant to most wastes, is used as an impermeable, flexible barrier to prevent interaction of landfill moisture with containminated wastes to form leachate which could have unwanted variable characteristics. High Density Polyethylene geomembranes are used in hazardous and non-hazardous landfills.
Features
- Manufactured to GRI-GM13 GR1-GM17 Specifications.
- Suitable for potable water or aquaculture.
- Excellent resistance to hydrocarbons for secondary containment.
- Excellent resistance to chemicals and most industrial effluents.
- Outstanding environmental stress crack resistance, dimensional stability and thermal ageing characteristics.
- Sheet dimensions allow fast installation.
Application
1) Environmental protection, sanitation (such as solid waste landfills, sewage treatment plants, power plants Chi-conditioning, industrial, hospital solid waste, etc.) .
2) Water (such as rivers, lakes and reservoirs of the anti-dam, plugging, reinforcement of the canal seepage, the vertical wall of the heart, slope protection, etc.).
3) Municipal Engineering (subway, on the ground floor of the building, planted roof, the roof garden of anti-seepage, sewage pipes lining, etc.).
4) Landscape (man-made lake, river, reservoir, golf courses reservoirs of the substrate, slope protection, green lawn of the waterproof moisture, etc.).
5) Petrochemical (chemical plants, oil refineries, gas storage tanks of the anti-chemical reaction tanks, sedimentation tanks of the lining, etc.).
Properties | Test Method | Value
| |||||||
ASTM D5199 | 0.75 mm | 1.00 mm | 1.25 mm | 1.50 mm | 2.00 mm | 2.50 mm | 3.00 mm | ||
Density(Min.) | ASTM D1505 | 0.940g/ml
| |||||||
Tensile properties | ASTM D6693 |
|
|
|
|
|
|
| |
*Yield strength KN/m |
| 11 | 15 | 18 | 22 | 29 | 37 | 44 | |
*Break strength KN/m |
| 20 | 27 | 33 | 40 | 53 | 67 | 80 | |
*Yield elongation |
| 12% | |||||||
*Break elongation |
| 700% | |||||||
Tear resistance N | ASTM D1004 | 93 | 125 | 156 | 187 | 249 | 311 | 374 | |
Puncture resistance N | ASTM D4833 | 240 | 320 | 400 | 480 | 640 | 800 | 960 | |
Stress crack resistance /h | ASTM D5397 | 300 | |||||||
Carbon black content | ASTM D1603 | 2.0-3.0% | |||||||
Carbon black dispersion | ASTM D5596 | 1 or 2 | |||||||
(OIT) Oxidative induction time | ASTM D3895 | 100 | |||||||
Low temperature impact brittle property at -70°C |
| Pass | |||||||
Dimensional stability /% |
| ±2 |
