Help CenterSell Metallized Film Lighting/Lamp Running Capacitor
Related Products
-
Sell Metallized Film Running CapacitorNegotiableMOQ: 1000 Pieces -
Sell Metallized Film Running CapacitorNegotiableMOQ: 1000 Pieces
-
Sell Air Conditioning CapacitorNegotiableMOQ: 1000 Pieces
-
Sell Metallized Film Running CapacitorNegotiableMOQ: 1000 Pieces
-
Sell Metallized Film Running CapacitorNegotiableMOQ: 1000 Pieces
Technical Data
1. Dry capacitors (epoxy, oil-free)
2. Plastic case (corrosion-free)
3. Voltage rating : 120V to 660V AC
4. Frequency : 50/60 Hz
5. Capacitance range: 1.0μF to 100.0μF
6. Capacitance : ± 5%
7. Temperature range : -25°C to 105°C max
8. Dissipation factor : 0.5% per one KHz
9. Approval : UL810.CUS and EIA-456.JIS-4908. and IEC
10. Plastic capacitors : models with leads or with terminals 6.35±0.1mm (quick connection; M 8 x 10mm)
11. Test voltage between terminals and containers : 3KV 60/50Hz for one minute
12. Test voltage : 1.75time RV, one minute
13. Pull test : Will sustain 2Kg steady pull in the direction of lead egress and 1Kg steady pull at any 90 degree angle for 60 seconds
After test, capacitor shall show no evidence of damage and pass all electrical requirements
