Annual output 50000m3 sand aac block production line

We offer full automatic AAC production line ,light weight block making machinery ,autoclaved aerated concrete block factory.

We offer full automatic AAC plant ,light weight block making machinery ,autoclave aerated block complete factory .

Areated concrete brick (light brick ) is the light and porous

buidling material. It has  light keeping temperature cant burn and other

advantages . it can be made into many kinds of bricks (for example :

600×200×100, 80×80×180 , 240×115×53, 600×200×125 ) ,they could be used industry

building and common building . they are more and more popular in the world .in

the future ,they will replace the Clay brick completely .

    2.Areated concrete common  conception

    Common concrete density is usually 1600-2400kg/m3,but Areated concrete are

500kg/m3,600kg/m3,700kg/m3.It has not the big grain ,main use silicon material

(for example: coal ash , sand , stone dust and others )   ,through making the

material small for example sand,they can be used directly if has enough degree

of small (for example coal ash.Mixing  calcium material lime cement water to a

special slop , then add the aluminum dust and the additive. Make the aluminum

dust and the special slop have a Chemical reflect . then produce Hydrogen to

make the concrete slop to expanding or swell,foam . Next , put them into the

curing room to concreting cutting steaming curing . last , there will bacome the

light brick . the porous rate is 70-80%.

    3. Advantages

     light weight

       Areated concrete density is usually 400-700kg/m3,(according the market ti

produce ),same as 1/3 of clay brick and  1/5 common concrete.So use the Light

brick can reduce the weight of the build more ,and also reduce the  beam of roof

and pillar press best . then you can see ,it can save the material and cost ,it

also fighting shaking .

     keeping temperature

     It has many are porous ,the delivery hearting coefficient is

0.9-0.22W/(mk),the same as  1/4 or 1/5 of clay brick ,so it is best  materials

now in the world .

      have many kinds material ,have lowest waste

Main Material : coal ash sand waste mine material coal stonestone dust and other

silicon materials .

       Save more energy

when produce 10000 m3 light weight brick ,will use  4200 Ton coal ash ,and save

coal ash using area 333sqare meters,save burning clay brick 333square meters .
