Copper Wire Drawing Machine
Negotiable
MOQ: 1 Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
poly
Place of Origin:
China
Model Number:
PL-B24
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
High Speed Medium Wire Drawing With Continuous Annealing MachineNegotiableMOQ: 1 Piece -
PL-14DT Medium Copper Wire Drawing Machine With Continuous AnnealingNegotiableMOQ: 1 Meter
-
PL-22DT Copper Wire Drawing MachineNegotiableMOQ: 1 Piece
-
Water Tank Wire Drawing MachineNegotiableMOQ: 1 Meter
-
Extemely Fine Wire Drawing MachineNegotiableMOQ: 1 Piece
Brand Name
poly
Place of Origin
China
Model Number
PL-B24
Fine copper wire drawing machine
THIS MACHINE BAS 3 MAIN PARTS
WIRE DRAWING PARTS
With area reduction's step cones. It drives by pulley and flat belt.
TAKE UP AND TENSILE CONTROL PART
Both wire drawing and spooler has an individual motor for precision cooperation the wire drawing speed also has a slanted pulley with individual motor and P.L.C. control program for full automatically without any manual adjustment.
AUTOMATIC LUBRICATING PARE
Automatic lubricating for main shaft and bearing with forced feed pump and filter to ensure the perfect lubricating.
| MODEL | PL194-B22 |
PL194-B24 |
PL120-B32 |
PL120-B22 |
| DIES QUANTITY | 22 | 24 | 32 | 22 |
| INLET WIRE DIA | 1.20-0.8mm | 1.0-0.5mm | 0.8-0.55mm | 0.2mm |
| OUTLET WIRE DIA | 0.35-0.08m/m | 0.35-0.08m/m | 0.2-0.05m/m | 0.2-0.05m/m |
| REDUCTION RATE | 15% | 13% | 15%.11% | 11% |
| SPEED | 2800m/min | 2800m/min | 2200m/min | 2200m/min |
| LUBRICANT | SPRAY TYPE | SPRAY TYPE | SPRAY TYPE | SPRAY TYPE |
| CAPSTAN | CERAMICS COATING | CERAMICS COATING | CERAMICS COATING | CERAMICS COATING |
| SHAFTS | five | five | seven | f |
| SHAFTS DRIVEN BY |
BELT | BELT | BELT | BELT |
| BEARING LUBRICATED |
spray type | spray type | spray type | spray type |
| SPOOL CPACITY | 40-70kg | 40-70kg | 40-70kg | 40-70kg |
| TAKE-UP | BY ELECTRICAL MAGNET |
BY ELECTRICAL MAGNET |
BY ELECTRICAL MAGNET |
BY ELECTRICAL MAGNET |
| BRAKE | BRAKE SYSTEM | BRAKE SYSTEM | BRAKE SYSTEM | BRAKE SYSTEM |
| TRAVERSE | BY ELECTRIC | BY ELECTRIC | BY ELECTRIC | BY ELECTRIC |
| SPOOL TAKE-UP | BY EXPANDING ARBOR | BY EXPANDING ARBOR | BY EXPANDING ARBOR | BY EXPANDING ARBOR |
| HORSEPOWER | AC×380V×15HP INVERTER |
AC×380V×15HP INVERTER |
AC×380V×20HP INVERTER |
AC×380V×71/2HP INVERTER |
| DIMENSION | 1760×1200×1680 | 1760×1200×1680 | 1850×1300×1700 | 1550×1200×1680 |
