Flattening machine -lever machine -cut to length part
Product Description
1)Preliminary leveling unit composed of power and main motor.
2)Power part is composed of leveling base, speed reducer, YWZ arrester, coupling, power distribute box, joint spindle joint sleeve, universal drive shaft and so on.
3)Main motor equip with high power direct current adjust motor and high capability direct current adjustment. With more high starting pitch of strand than rating, less voice and good reliability.
4)Main motor is separated up and down two rolls each part. Composed of machine base, double housing type frame, 15 leveling rolls (7 up and 8 down), up/down bearing base, beam, roll support frame, worm wheel and worm pole drive to control the upper roll come up and down. Two speed reducers adjust the distance of up and down in entrance and exit rolls. Simple adjustment manually, display on the percent gauge. Leveling working roll diameter is 140mm, 42Cr Mo material.
5)Its forming procures is modulator and intermediate frequency quench and surface plating Cr precise grand, no mark on the surface of sensitivity material. The hardness of leveling working roll is HRC55-58.
6)We adopt needle roller bearing and plane bearing support leveling roller so as to reduce the resistance of whole system. Two sides of the upper roll axial seat is arc rail structure, can adjust the entrance and exit distance between the upper and lower rolls.
7)The rolls joint with universal drive shaft and power distribute box, both is initiative move, with high precise.
Nantong Atlantic Machinery Co.,Ltd is a jointed venture with investment from HongKong and Germany,founded in 1969,which specialized in making machines for sheet shearing and bending ."Atlantic"brand machines have a good reputation at home and abroad ,machines produced here are with DIN standard.
Here we can ensure good quality and reasonable price machines for you .Welcome your arrival and looking forward to cooperating with you !
Our company details:
|
Product Trademark: |
"Atlantic" |
|
Products we can supply |
Shearing machine、Press brake、Rolling machine、 cut to length line |
|
Standard: |
Germany |
|
Productivity: |
55 Sets per month |
|
Contact person |
Xiaohua Shen (Mr.Allen Shen) |
|
Mobile: |
0086-13584714567 |
