Help CenterAPD ONU 2*2 Inch Triplexer Optical GPON Transceiver 1310nm T / 1490nm R
Related Products
-
OLT BIDI SFP Transceiver 20Km , Fiber Optical Bi - Directional ModuleNegotiableMOQ: 1 Piece -
ONU BIDI SFF Receptacle GPON Module 2.5Gb/s , EPON TransceiverNegotiableMOQ: 1 Piece
-
2.5Gb/s Single Mode GPON Transceiver Complies With SFF-8472 Rev 9.5NegotiableMOQ: 1 Piece
-
Full Compatible ONU BIDI SFF Optical Transceiver 1.25Gb/s TX / 2.5Gb/s RXNegotiableMOQ: 1 Piece
-
Gigabit - Capable Passive Optical Networks GPON Transceiver Complies With SFF MSANegotiableMOQ: 1 Piece
Certification:TUV/ FCC/ UL/ROHS/FDA
Single fiber triple-directional data links
1244Mbps 1310nm DFB burst mode transmitter, LVPECL compatible data input interface
2488Mbps 1490nm APD-TIA continuous mode receiver, CML compatible data output interface
47M~870MHz 1555nm Video Bandwidth analog receiver, 18dBmV minimum RF output power, Feedback Video ACG
Operation
0 to 70°C operating case temperature for C-temp class, and -40 to 85°C operating case temperature for I-temp class
2x2 inch TRIPLEXER package with SC/APC pigtail connector
3.3V and 12V power supply
LVPECL differential or single ended LVTTL burst enable control
LVTTL RESET, SD, TX_SD signal functions
Low EMI and excellent ESD protection
Class I laser safety standard IEC-60825 compliant
RoHS-6 compliance
Specifications:
|
P/N |
SOGP3412-TA(I)GA |
|
Data rate: |
2.5Gb/s |
|
Distance |
CLASS B+ |
|
Wavelength |
1310nm T/1490nm R |
|
Transmitter |
DFB |
|
Receiver |
APD |
|
DDM |
Yes |
|
Connector |
SC |
|
Operating Temperature |
-0~70℃ |
|
Voltage Supply |
3.3V |
|
Brand |
Superxon |
|
Certification |
TUV/FCC/UL/ROHS/ FDA/CDRH |
APPLICATIONS
Gigabit-capable Passive Optical Networks (GPON) ONT with video applications
STANDARDS
Complies with ITU-T G.984.2, G.984.2 Amendment 1, G.984.2 Amendment 2
Complies with ITU-T G.984.5
Complies with FCC 47 CFR Part 15, Class B
Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007
Competitive Advantage:
1. Excellent quality with 2 years warranty
2 Keep stock , Fast delivery
3 Competitive pricing
4 OEM/ODM Customized label
