Micro White Multifunction USB Cable 30 Pin For IPhone 4 / Samsung / IPod

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	AIBUSI		Place of Origin	China
Model Number	ABS-C19

Product Description

Delivery Time:5-10 days
Certification:CE,ROHS, FCC

Micro White Multifunction USB Cable 30 Pin For iPhone 4 / Samsung / iPod

Quick Detail:

Name

2 in 1 charge &sync usb cable for iphone4S/Samsung/Blackberry

Brand Name

ABS-C18

Color

white,black,yellow,

green,blue.Pink

Feature

USB AM to iphone4s+iphone5/5S TPE Materieal, With DATA+Charge Func,in each port

Place of origin

Guang dong china (mainland)

Certificate

CE,RoHS, FCC

Production Introductions:

With Micro and apple 30 pin connectors,it is compatible with iphone4,ipod,iphone4s and Samsung using Micro usb jack.

Production Description:

1,Sync data or charging 2,Can be through the Dock direct or indirect. 3,Connect to the iphone4/4s ,Samsung ,blackberry and most mobile phones etc to computer USB port, in order to achieve efficient sync data transmission and the charging function. 4,100% brand new & high quality 5, Wide-body wire, not knot, convenient use 6, Many colors, more fashion, more personality

Wire rod Description:

1. No.of cond:4 Conductors

2. Conductor 1

a, Material: Enameled Copper Wire 1 UEW

b, Construction: 0.06mm/18 strands

c, Fillers: Nylon Silk White 250D

3. Conductor 2

a, Material: Enameled Copper Wire 1 UEW

b, Construction: 0.06mm/30 strands

c, Fillers: Nylon Silk White 250D

4. Jacket

a, Material: NON Migration TPE Dull Surface

b, Diameter:2.0*5.5mm

c, Way of Extrusion :Solid

Construction
ITEM	DESCRIPTION
No.of Cond	4 Conductors
Conductor(1)	Material/Color	Enameled Copper Wire 1 UEW / According to the picture ( 1 , 4 )
Construction	0.06 mm / 18 strands
Fillers	Nylon Silk White 250D
Conductor(2)	Material/Color	Enameled Copper Wire 1 UEW / According to the picture ( 2 , 3 )
Construction	0.06 mm / 30 strands
Fillers	Nylon Silk White 250D
Jacket	Material/Color	NON Migration TPE Pass ROHS/Green Dull Surface
Diameter	2.0 * 5.5mm
Way of Extrusion	Solid

DESCRIPTION:［(0.06/18+250D)2C+(0.06/30+250D)2C］*1F
TITLE: 2.0 * 5.5 4C TPE
NO	Conductor
1	Blue
2	Nature
3	Red
4	Green

Characterisitcs:

Conductor Resistance:Resistance shall not exceed 0.6 ohms/m Withsand Voltage test: No Breaking (250 VAC/1min,between two wires) Insulation Resistance:Shall not less than 10 Mohms·m(250 VAC/1min,between two wires) NON Migration Test: N0 Trace (500g;60℃;ABS;48H)

ITEM	Condition	SPEC
Conductor Resistance	￣	Resistance shall not exceed 0.6 ohms/m
Withstand Voltage Test	250 VAC / 1 min , between two wires	No Breaking
Insulation Resistance	250 VAC / 1 min , between two wires	Shall not less than 10 Mohms·m
NON Migration Test	500g ; 60℃; ABS ; 48H	NO Trace
Bending Test	Load	Angle	Diameter	Jig	Bend Radius	Frequency	Requirement	Not to cut off Wire
200g	±90	￣	√	R25.4	30/min	min:3000
Envirommental Protection	ROHS	Accord with
