Home > Consumer Electronics > LED Display > Indoor LED Display > 3 Axis CNC Spiral Bevel Gear Chamfering Machine 25kw , Good Stablity

3 Axis CNC Spiral Bevel Gear Chamfering Machine 25kw , Good Stablity

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

JJR

Place of Origin:

China

Model Number:

YK9255

Contact Supplier Request Quote Chat Now

China Gear Cutting Machine Online Market

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name JJR

Place of Origin China

Model Number YK9255

Delivery Time:1month
Certification:ISO9000

3 Axis CNC Spiral Bevel Gear Chamfering Machine 25kw , Good Stablity

Quick Detail:

YK9255 Machine tools are used for spiral bevel gears (wheels) cone intersection of involute tooth surface and surface machining chamfering machines. Through the chamfering process of gear can make to reduce noise in gear meshing process, reliable transmission, improving accuracy, avoiding artificial chamfering edges uneven width and prevent environmental pollution caused by adverse factors such as.

Description:

The machine adopts Germany Siemens 802D CNC system, with three CNC axes: the horizontal axis (x axis), table rotation axis (the y axis), vertical linear axis (z axis) to realize three axes and use finger wheel, grinding wheel spindle spindle-driven, intuitive and convenient operation, the stability is good.

In terms of software with powerful computing capabilities, for calculation of chamfering of almost all included, precision high, achievable human-machine interface. Grinding head spindle of machine tools in a different structure: rigid, flexible grinding grinding. Hydraulic clamping the workpiece, grinding and dressing of grinding wheel use automatic completion of the whole process.

The machine used on artificial, feeding method.

Specifications:

1.cutting range
modulus	m	4.5～13
day drive		φ200～φ550
pitch angle		60°～85°
2.wheel speed	m/s	max 50
3.Main drive power (Spindle)	kw	2.2~3
4.Total power	kw	25
5. Chamfer width	mm	max 1
6. Dimensions
Host Dimensions	mm	2100×1500×2500
Overall Dimensions	mm	2100×2500×2500
7.The overall weight of the machine	t	About 6

Company Profile:

Heng Yong company gathered many experienced experts. This team is lead by people have over decades of experience, and filled with young, energetic engineers. With strong research and developing ability, our company put extraordinary effort on developing complete sets of gear machinery. Now we are able to provide our customer the main products as follows: Gear Shapers, Straight Bevel Gear Generators, Spiral Bevel Gear Generators, Spiral Bevel Gear Grinders, Hypoid Gear Testers, Gear Lappers, Gear Quenching Press, Gear Chamfering Machines, Gear Hobbers, Honing Machines, Vertical & Horizontal Machining Centers, Special Precision Speed Reducers, Roll Stander for Seamless Tube Stretch Reducing Mill, Gear Coupling Family, Low Drive Devices and Environmental Protective Equipment of 16 kinds, more than 30 families, and more than 150 types and specifications. The company focus on developing heavy-duty, large CNC gear machinery, which are urgently needed by the government and makes industrialize as soon as possible, provide a great variety of advanced gear machinery to the market. The company is using the leading 3D designing software for developing and designing. The company combines producing with research and development by Cooperating with TIANJIN University and other colleges for many years.
