1060mm Trapezoidal Roof Sheet Roll Forming Machine With C r 12 Cutting Blade

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TECHWELL		Place of Origin	China
Model Number	TW-RWM

Product Description

Delivery Time:55-65 working days
Certification:CE

1060mm Trapezoidal Roof Sheet Roll Forming Machine With C r 12 Cutting Blade

Characteristic of Trapezoidal Roof Sheet Roll Forming Machine

This Trapezoidal Roof Sheet Roll Forming Machine can rollform iron steel trapezoidal roofing sheet. After roll formed by this roof roll forming machine, the surface of metal roofing is very smooth and beautiful without any scratch on the surface of roofing sheets. The Trapezoidal Roof Profile Roll Forming Machine is with fully automatic control system with PLC. Easy operation: Key in the length and quantity on the control panel. We also can do a custom roll forming machine, we can design machine according to your specifications and profile drawings.

Specifications of Trapezoidal Roof Sheet Roll Forming Machine

Item	Trapezoidal Roof Sheet Roll Forming Machine
Coil Material	Thickness	0.3-0.8mm
Coil width	Custom-made, 1000mm or 1200mm or 1250mm
Yield Strength	250-350 Mpa
Material	PPGI, Color Steel, GI.
Decoiler / Uncoiler	Uncoiler Type	Manual or Hydraulic or Auto Type
Coil Width	Max. 1250mm
I.D	508-610mm
O.D	Max. 1500mm
Trapezoidal Roll Forming Machine	Forming Stations	16-18 Stations ( Depend on Profiles )
Roller material	45# steel, surface coated with 0.05mm hard chrome
Diameter of shaft	76mm
Shaft material	High grade 45# steel
Drive type	Chain transmission
Forming speed	0-15m/min
Main power	5.5KW
Cutting To Length Device	Cutting type	Hydraulic cutting
Cutting Die Material	Cr12Mov steel, HRC58-62
Cutting power	3KW
CuttingTolerance	10m1.5mm
Encoder	OMRON Brand
PLC Electrical Control System	PLC	PANASONIC Brand
Inverter	YASKAWA Brand
Touch screen	PANASONICE
Operation type	Touch screen & Button
Hydraulic Station	Hydraulic station	Famous Chinese brand
Support Tables	Table type	Simple nonpower type
Function	To support the finished panels

Maintenance of Trapezoidal Roofing Sheet Roll Forming Machine

Daily maintenance plays an very importance role in extending the operation time and of roof wall sheet roll forming machine and the good quality finished roof wall panel. The following points should be part of the machine\'s daily production and usage routine.

Regularly lubricated the outside parts of the trapezoidal roofing sheet roll forming machine, such as the driving chain... Regularly brush the surface of roller, particularly when working outside. If you do not use the trapezoidal sheet panel forming machine in a long time, you should apply luricating oil on the roller surface, make sure you clean it for next time running machine. If the trapezoidal roofing sheet roll forming machine is not operated in a long period, should cover it with plastic film, to avoid getting rain or dust on the machine, or avoid the machine becoming dampt, especially the PLC electric control board. Make sure the cu
