13 - 20 Forming Station Roof Wall Roll Forming Machine for Metal Roofing Sheet TW-RWM
Characteristic of Roof Wall Sheet Roll Forming Machine
This Roof Wall Sheet Roll Forming Machine can rollform metal roofing sheet. After roll formed by this roof roll forming machine, the surface of metal roofing is very smooth and beautiful without any scratch on the surface of roofing sheets. The Roof Wall Cladding Sheet Roll Forming Machine is with fully automatic control system with PLC. Length, quantity of sheets is adjustable. Rollforming process: Uncoiler, Rollforming, Cut to length. 1 Year warranty, lifelong time service. Easy operation: Key in the length and quantity on the control panel. We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.Maintenance of Roof Wall Panel Roll Forming Machine
Daily maintenance plays an very importance role in extending the operation time and of roof wall sheet roll forming machine and the good quality finished roof wall panel. The following points should be part of the machine\'s daily production and usage routine.
Regularly lubricated the outside parts of the roof wall roll forming machine, such as the driving chain... Regularly brush the surface of roller, particularly when working outside. If you do not use the roof panel forming machine in a long time, you should apply luricating oil on the roller surface, make sure you clean it for next time running machine. If the roof wall sheet roll forming machine is not operated in a long period, should cover it with plastic film, to avoid getting rain or dust on the machine, or avoid the machine becoming dampt, especially the PLC electric control board. Make sure the cutting system is lubricated when necessary. Check the Hydraulic station often and the oil quantity of the deceleration machines, add more oil if the oil level is low. Check the electric appliances box and every leads conjuction circumstance of the roof wall roll forming machine.Specifications of Roof Wall Sheet Roll Forming Machine
| Item | Roof Wall Sheet Roll Forming Machine | |
| Coil Material | Thickness | 0.3-0.8mm |
| Coil width | Custom-made, 1000mm or 1200mm or 1250mm | |
| Yield Strength | 250-350 Mpa | |
| Material | PPGI, Color Steel, GI. | |
| Decoiler / Uncoiler | Uncoiler Type | Manual or Hydraulic or Auto Type |
| Coil Width | Max. 1250mm | |
| I.D | 508-610mm | |
| O.D | Max. 1500mm | |
| Roof Wall Roll Forming Machine | Forming Stations | 16-18 Stations ( Depend on Profiles ) |
| Roller material | 45# steel, surface coated with 0.05mm hard chrome | |
| Diameter of shaft | 76mm | |
| Shaft material | High grade 45# steel | |
| Drive type | Chain transmission | |
| Forming speed | 0-15m/min | |
| Main power | 5.5KW | |
| Cutting Device | Cutting type | Hydraulic cutting |
| Cutting Die Material | Cr12Mov steel, HRC58-62 | |
| Cutting power | 3KW | |
| CuttingTolerance | 10m1.5mm | |
| Encoder | OMRON Brand | |
| PLC Electrical Control System | PLC | PANASONIC Brand |
| Inverter | YASKAWA Brand | |
| Touch screen | PANASONICE | |
| Operation type | Touch screen & Button | |
| Hydraulic Station | Hydraulic station |
