5.5 Kw Automatical Aluminium Corrugated Sheet Roll Forming Machine For Corrugated Sheets
Negotiable
MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
TECHWELL
Place of Origin:
China
Model Number:
TW-RWM
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Standard 686mm IBR Sheet Roll Forming Machine With PLC Control SystemNegotiableMOQ: 1 Ton -
Widespan IBR Roll Forming Machine With Hydraulic Cutting, Panasonic PLC Control SystemNegotiableMOQ: 1 Ton
-
Metal Roof IBR Sheeting Roll Forming Machine For 0.3 - 0.8mm Material ThicknessNegotiableMOQ: 1 Piece
-
IBR Sheet / Sheeting Making Machine With PLC Frequency Control SystemNegotiableMOQ: 1 Piece
-
Standard Wide Span IBR Roofing Sheet Roll Forming Machine With 5.5 Kw Main Motor PowerNegotiableMOQ: 1 Set
Brand Name
TECHWELL
Place of Origin
China
Model Number
TW-RWM
Delivery Time:55-65 working days
Certification:CE
Certification:CE
5.5 Kw Automatical Aluminium Corrugated Sheet Roll Forming Machine For Corrugated Sheets
Specifications of Aluminium Corrugated Sheet Roll Forming Machine
| Item | Aluminium Corrugated Sheet Roll Forming Machine | |
| Coil Material | Thickness | 0.3-0.8mm |
| Coil width | Custom-made, 1000mm or 1200mm or 1250mm | |
| Yield Strength | 250-350 Mpa | |
| Material | PPGI, Color Steel, GI. Aluminium | |
| Decoiler / Uncoiler | Decoiler Type | Manual or Hydraulic or Auto Type |
| Coil Width | Max. 1250mm | |
| I.D | 508-610mm | |
| O.D | Max. 1500mm | |
| Corrugated Sheet Roll Forming Machine | Forming Stations | 16Stations ( Depend on Profiles ) |
| Roller material | 45# steel, surface coated with 0.05mm hard chrome | |
| Diameter of shaft | 76mm | |
| Shaft material | High grade 45# steel | |
| Drive type | Chain transmission | |
| Forming speed | 0-15m/min | |
| Main power | 5.5KW | |
| Cutting System | Cutting type | Hydraulic cutting |
| Cutting Die Material | Cr12Mov steel, HRC58-62 | |
| Cutting power | 3KW | |
| CuttingTolerance | 10m1.5mm | |
| Encoder | OMRON Brand | |
| Electrical Control Board | PLC | PANASONIC Brand |
| Inverter | YASKAWA Brand | |
| Touch screen | PANASONICE | |
| Operation type | Touch screen & Button | |
| Hydraulic Station | Hydraulic station | Famous Chinese brand |
| Runout Tables | Table type | Simple nonpower type |
| Function | To support the finished panels |
Main Components of Corrugated Sheet Roll Forming Machine
| Decoiler / Uncoiler | 1 Unit |
| Feeding Guide | 1 Unit |
| Main Corrugated Sheet Roll Forming Machine | 1 Unit |
| Hydraulic Cutting Device | 1 Unit |
| Hydraulic Station | 1 Unit |
| PLC Computer Control Board | 1 Unit |
| Runout Tables | 2 Units |
Maintenance of Corrugated Sheet Roll Forming Machine
Daily maintenance plays an very importance role in extending the operation time and of Corrugated sheet roll forming machine and the good quality finished corrugated sheets. The following points should be part of the machine\'s daily production and usage routine.
Regularly lubricated the outside parts of the Corrugated sheets roll forming machine, such as the driving chain... Regularly brush the surface of roller, particularly when working outside. If you do not use the Corrugated sheet forming machine in a long time, you should apply luricating oil on the roller surface, make sure you clean it for next time running machine. If the corrugated roofing sheet roll forming machine is not operated in a long period, should cover it with plastic film, to avoid getting rain or dust on the machine, or avoid the machine becoming dampt, especially the PLC electric control board. Make sure the cutting system of corrugated roof panel forming machine is lubricated when necessary. Check the Hydraulic station often and the oil qu
