85 mm Diamond Core Drill Bits For Rock , Diamond Impregnated Drill Bits
- T/T L/C D/P D/A
- 7 days
You May Like
-
Exploration Mining Diamond Tip Core Drill Bits for Concrete 122 mm
-
Mining Drilling Core Barrel Assembly / Wireline NMLC Core Barrel Triple Tube
-
Q Series HQ Core Barrel Assembly Wireline Drilling Tools Machining Casting
-
96 mm HMLC Core Barrel Assembly Triple Tube Drilling For Hard Rock
-
NQ HQ Triple Tube Core Barrel / Double Core Barrel Diamond Drilling
-
Drilling Tools Double Tube Core Barrel , Triple Core Barrel 1.5M / 3M Length
Product Details
| Brand Name | Master Core & Core-XZ | Place of Origin | China | |
| Model Number | PQ |
Product Description
Certification:ISO API
85 mm Diamond Core Drill Bits For Rock , Diamond Impregnated Drill Bits Specifications
2. various waterways design.
3. long bit life and good performance.
To select the right bit for the job, assess the speed and power of your drill for the size and depths of the holes to be drilled and assess ground conditions such as rock type/formation and down-hole conditions.
Size: Our company's bits are available in all standard drilling sizes . Also, non-standard sized bits can be produced according to requirements from clients.
Martrix Height: we offers crown impreg depths of 9mm, 12mm, 16mm .The taller crown heights provide improved bit stability and reduced vibrations, enhancing bit life and performance.
Waterways: Various waterways are available for diamond impregnated bits. Differing waterways allow for better flushing in various ground conditions and drilling systems.
Threads:
standard threads as well as regional thread types required by clients are available.
Compatibility:
Our diamond bits and reaming shells are designed to be compatible with all standard core barrels from other suppliers.
Non-standard also can be made as your requirement.
Application
Our impregnated bits matrices can be selected according to the chart below
|
Series Number |
Name of Rock |
| 1 | sand, soft shale, chalk, marly shale, med-hard limestone ,salt,frozen soil&ice,soft sandstone,sandy shale,claystone,sandy limestone,soft schist |
| 2-3 | soft shale,chalk,marly shale,med-hard limestone,salt,frozen soil&ice,soft sandstone,sandy shale,claystone,sandy limestone,soft schist,med-hard sandstone,siltstone,alluvial deposits,calcitic limestone |
| 4-5 | claystone,sandy limestone,soft schist,med-hard sandstone,siltstone,alluvial deposits,calcitic limestone,med-hard limestone,hard limestone,hard shale,dolomitic limestone |
| 6-7 | med-hard limestone,hard limestone,hard shale,dolomitic limestone,schist,serpentine,hard & mica schist,siliceous limestone,dolomite,marble,peridotite |
| 7-8 | dolomitic limestone,schist,serpentine,hard & mica schist,siliceous limestone,dolomite,marble,peridotite,andesite,pegmatite,hematite |
| 8 | dolomite,marble,peridotite,andesite,pegmatite,hematite,magnetit,metamorph schist,gneiss,granite,basalt |
| 9-10 | andesite,pegmatite,hematite,magnetit,metamorph schist,gneiss,granite,basalt,gabbro,rhyolite,diorite |
| 10-11 | magnetit,metamorphschist,gneiss,granite,basalt,gabbro,rhyolite,diorite,conglomerate,taconite |
Technical Parameters:
