Hydraulic 45# Steel Cold Roll Forming Machine Sheet Metal Forming Equipment
- T/T L/C D/P D/A
- 7 days
You May Like
-
Cr12 Color Steel Frame Roll Forming Machine For Garage / Security Door
-
400mm 45# Steel Ridge Cap Roll Forming Machine Roof Tile Roll Forming Machine 3+3kw
-
Professional Hydraulic Ridge Cap Roll Forming Machinery 380V 50Hz 3 Phases
-
Custom Cr12 Ridge Cap Roll Forming Machine , 3kw 400mm Roofing Roll Forming Machinery
-
IRB Steel Roof Panel Cold Roll Forming Equipment With PLC Panasonic
-
Full Automatic Cr12 C Purlin Roll Forming Machine For Prefab House
Product Details
| Brand Name | HC | Place of Origin | China | |
| Model Number | HC760 |
Product Description
Certification:ISO
Shutter Door Forming Machine
Quick Detail:
1. Suitable to process: Color steel plate
2. Width of the plate: 1000mm
3. Rollers: 18rows
4. Dimensions: 8.6*1.45*1.51m
5. Power: 3+3kw
6. Rolling material: 45# steel(plated chrome on surface)
7. Thickness of the plate:0.3-0.6mm
8. Voltage: 380V 50Hz 3phases
9. Material of the cutting plate: Cr12
10. Hydraulic: 40#
11. Processing precision: Within 1.00mm
12. Control system: PLC control
Description:
Rolling Shutter Door Roll Forming Machine Main parameter
|
No. |
Main parameter of Rolling Shutter Door Roll Forming Machine |
|
|
1 |
Suitable to process |
Color steel plate |
|
2 |
Width of the plate |
1000mm |
|
3 |
Rollers |
18 rows |
|
4 |
Dimensions |
8600*1450*1510mm |
|
5 |
Power |
3+3kw |
|
6 |
Rolling material |
45# steel(plated chrome on surface) |
|
6 |
Thickness of the plate |
0.6mm |
|
7 |
Productivity |
20m/min |
|
8 |
Diameter of the roller |
Φ66 mm |
|
9 |
Voltage |
380V 50Hz 3phases |
|
10 |
Material of the cutting plate |
Cr12 |
|
11 |
Hydraulic |
40# |
|
12 |
Processing precision |
Within 1.00mm |
|
13 |
Control system |
PLC control |
Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-cutting
Application
This type of sheet can be widely used as the door of garage, storage and supermarket.
Competitive Advantage
1. ISO/CE certification
2. 20sets/ month
3. high-speed production
4. easy operate, easy maintain
5.One year free warranty
