Home > Products > Water Treatment Equipments > 3T / H Pure Water Treatment Equipments For Bottled Water Production Line
3T / H Pure Water Treatment Equipments For Bottled Water Production Line
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
RO pure water equipment configuration , Water Treatment Equipments
-
4T / H reverse osmosis water treatment equipment For Mountain Water
-
4T Purified , Pure , mineral Mineral Water Treatment Equipment
-
100 Barrels/Hour 5 Gallon Automatic Bottle Filling Machine For Juice / Wine CXGF16
-
4T / H pure Water Treatment Equipments For Drinking Water
-
10T / h Water Treatment Equipments , Water Treatment Machine
Product Details
| Brand Name | TONGDA | Place of Origin | China | |
Product Description
Certification:ISO
A.3T raw water tank
1, Material: PE
B, the mechanical filter
1, ¢ 700 * H2100
2,304 Material, S = 2MM
3, filter: 500kg quartz sand layer thickness
4, the positive backwash pipe valve 304 stainless steel
C.the activated carbon filter
1, ¢ 700 * H2100
2,304 Material, S = 2MM
3, Media: shell-type activated carbon 250kg
4, the positive backwash pipe valve 304 stainless steel
D. the sodium ion exchanger
1, ¢ 700 * H2100
2,304 Material, S = 2MM
3, Media: shell-type activated carbon 250kg
4, the positive backwash pipe valve 304 stainless steel
5, the reproducing apparatus: 103 plastic pump, 300L renewable liquid barrels (PE)
E.reverse osmosis unit
1, precision: ¢ 250 * 1200, PP meltblown 6
2, the high-pressure pump: CDL8-130 South Pump
3, RO membrane: U.S. Navy was able company, ESPA2 4040,12 support
4, the controller: Dedicated RO Control Module
5, stainless steel housing: 2 m long 6
6, electrical boxes, racks are stainless steel
7, conductivity meter: 2. Flowmeter: 2. Pressure Controller: 2
8, the cleaning tank: 300L (PE)
9, the cleaning pump: CHL4-30 South Pump
10, solenoid valve, connecting pipe valves are stainless steel
F. 3T storage tank
  1 barrel: 2mm304 stainless steel
  2, with level display, level control, some holes, and out, outlet, 0.2um respirator
G. all stainless steel UV sterilizer
  1, Power: 500WH. pure water pump
  1, CHL4-30 South Pump
I. 2T storage tank
  1 barrel: 2mm304 stainless steel
  2, with level display, level control, some holes, and out, outlet, 0.2um respirator
