Flush In Pavement Green Heiport Touchdown Lights for TLOF FAA Compliance
Specifications:
| Light Characteristics | |||
| International standard | ICAO Annex 14 volume II; Heliports | Effective intensity | Compliance to ICAO Heliports; Photometric; |
| Light technology | Ultra bright LED | Available color | Green(Others option) |
| Flash | Fixed(no flash) | Operation mode | Wire |
| Electrical Characteristics | |||
| Operation mode | Wire | Operation voltage | 220V AC; 48V DC |
| Consumption | 10 Watts | Multi-lights connection | In parallel |
| Physical Characteristics | |||
| Body material | Casting aluminum alloy | Lens material | Polycarbonate |
| Mounted type |
Inset mounted | Mounting | Grounting |
| Overal dimension | ∮220mm×130mm | Net weight | 6.5kg |
| Working temperature | -40c degree to +60c degree | Waterproof rating | IP68 |
| Environmental Factors | |||
| Humidity | 0 to 98% | ||
| Altitude | ＜4500m | ||
| Wind speed | Up to 80m/s | ||
| Others | |||
| ISO pass | ISO9001:2008 | ||
Description:
1. FATO and TLOF area both used with Flush in-pavement Green lights to light up the edge of TLOF.
2. The helipad Lighting system always consist of elevated/flush perimeter lights and floodlighting.
3. Custom solutions is available like operation voltage, color yellow, blue, red.
4. Casting aluminum alloy strong body.
5. Rating IP68 for ingress grade.
6. 2 ways cable out from bottom / side easy for cable connection for optional.
7. Polycarbonate lens very good impact resistence.
8. Light source using high power LED with an expectancy lifespan 100,000 hours.
9. Built in surge protection device, can be used in the harsh environment.
Applications:
| Surface Heliports | Hospital; hotel; pilot training; army;private. |
| Elevated Heliports | Hospital; hotel; high rise building |
| Offshore | Oil drilling platform, ship board;Navy;LNG |
| Airfield Lighting | Small Airfield |
Competitive Advantage:
PLUSAFE SOLUTIONS LIMITED (P.S.L) providing reliable and costing products and services. Based on our experienced technical teams and qualified factory the lights are manufactured followed by ICAO, FAA and relevant regulations. We value our customer needs and honesty is 1st in our culture.
Supply all range of aviation lights and customize service. Focus on LED Technology Solutions development. Reasonable price and good service.
