sawing machine

Ⅰ Usage

The horizontal profile band sawing machine is progressive sawing equipment, mainly used in process various metal such as carbon structural

steel, low alloyed steel , high alloyed steel, special alloyed steel and stainless acid resistant steel and so on.

It can also work non-ferrous metal and the non metallic material if the suitable saw band is chosen.

Ⅱ Main technical parameters and features

1. GW4025, G4028A main technical parameters

  Max. process dia.: 280mm         Max. process size: 150X350mm

   Saw band length: 3505mm    Saw band width: 27mm   Saw band thickness: 0.9mm

   Process speed (m/min) 25, 35,45, 55,77 (three speeds)

   Feeding speed: hydraulic control (stepless speed variation)

   Motor power:

   Saw band transmission     2.2KW (4 grades)

   Hydraulic transmission     0.55KW (4 grades)

   Hydraulic tank capacity               12L

   Cutting agent tank capacity             38L

   Hydraulic pump (CB-B6)   Pressure 2.5Mpa   Flow 6L/min

Pump for cutting agent      Max lift       3m

                                Max flow       12L/min

Overall dimension of machine (LXWXH) 1750X1045X1160mm

Permissible loading                1500Kg

Machine weight              800Kg

GW6528 main technical parameters

Max. process dia.: Φ280mm

   Max process width: 650mm

   Saw band length: 3900mm      Saw band width: 34mm    Saw band thickness:1.1mm

   Process speed (m/min) 27, 46, 69(three speeds)

   Feeding speed: stepless speed variation

   Saw band transmission    3KW (4 grades)

   Hydraulic transmission    0.55KW (4 grades)

      GW4035, GW4038 main technical parameters

   Max. process dia.: 280mm

   Saw band length: 4115mm   Saw band width: 34mm   Saw band thickness: 1.1mm

   Process speed (m/min) 27, 46, 69 (three speeds)

 Feeding speed: stepless speed variation

Saw band transmission     3KW (4 grades)

   Hydraulic transmission      0.55KW (4 grades)

Hydraulic tank capacity                15L

   Cutting agent tank capacity             50L

   Hydraulic pump    2.5Mpa            Flow    6L/min

   Pump for cutting agent   40W

GW4040 main technical parameters

Max. process dia.: 400mm

   Saw band length: 4490mm   Saw band width: 41mm   Saw band thickness: 1.3mm

Process speed (m/min) 27, 46, 69 (three speeds)

Feeding speed: stepless speed variation

  Saw band transmission    3KW (4 grades)

  Hydraulic transmission     0.55KW (4 grades)

2. Features:

      It is ideal blanking equipment suitable for processing various kinds of metal. It exhibits high accuracy, high production efficiency, low material consumption and low energy consumption and so on.
