ZHONGBO Transmission Assembly Efficiency Testing Test Bed/Base Plate/Test Bench
Material:HT200-250
Size: 100mmx100mm-8000mmx5000mm
Precision
Grade:0.1.2.3
Standard:JB/T7974-99
Cast iron bed plates are used in Engineering industries as rigid bases
for layout, marking, inspection,
assembly work.
Cast Iron T-Slotted Floor Plates are used in engineering industries as
rigid bases for layout, marking,
inspection, assembly work, large fixtures,special tooling and production set ups, as also for mounting jobs for
precision welding or for carrying out machining operations like drilling, boring etc. and also as test beds for
mounting engines, large machines, transmission or other industrial equipments.
Clamping Plates
suitable for use as table or bed for light duty work like layout, marking, inspection,
testing, assembly, set ups, light fabrication etc. These are machined on top, bottom and two
longitudinal edges. Ends are machined only upon request. This plates can be encased into concrete
for by filling grout material underneath plate
The base plate is used for mounting engine and dynamometer. T-slot spacing is designed under the dynamometer dimension.
The base plate is used for mounting engine and dynamometer. Base plate is made with HT200 cast iron.Surface has tempering aging treatment before cutting. On the base plate surface there are certain T-slots for the installation of dynamometer, engine mounting brackets and throttle actuator etc. The base plate dimension is designed with the consideration of engine power. T-slot spacing is designed under the dynamometer dimension
Your consulting are warmly welcome.
If any inquiries,pls send email to zhongbo0903(@)
