WAW-300D Series Computer Control Servo Hydraulic Universal Testing Machine+Load cell+Scientific equipment
Main Applications & Functions:
WAW-300D Series Computer Control Servo Hydraulic Universal Testing Machine, compared with a ball screw type electric mechanical UTM, is adopting oil hydraulic power to push the piston in the oil cylinder to provide loading force. Therefore it is very suitable for making test to different metal and nonmetal materials under high toughness and hardness against extreme big loading force.
Features
1>Using the LOAD CELL test the force.
2>Full computer controlled of testing process.
3>Adopt oil-hydraulic automatic clamps which can be operated from separate control box
4>Wedge tension jaw processed by advanced technology; increase the stiffness of crosshead under high load and high intensity test.
5>Powerful multifunctional control software will provide more testing methods to meet ASTM, ISO and other testing standards.
6>Report guide will create your testing report in only three steps.
7>Programmable testing software makes LCF testing or cyclic testing become available.
8>Overload protection will secure operators.
Technical specification:
|
Mode |
WAW-300D |
|
|
Max. Load capacity |
300KN |
|
|
Load accuracy |
Within ±1% |
|
|
Test space |
Tensile |
550mm |
|
Compression |
500mm |
|
|
Piston stroke |
200mm |
|
|
Distance between columns |
450mm |
|
|
Tensile fixture |
Round specimen fixture |
Φ10-Φ20mm Φ13-Φ26mm |
|
Flat specimen fixture |
0-15mm |
|
|
The width of flat specimen |
70mm |
|
|
Flat size |
Φ160mm |
|
|
Bending adjust space |
400mm |
|
|
Dimension |
750*600*2100mm |
|
|
Power supply |
Three-phase 380V 50HZ (special requirement can be met) |
