High Brightness Outdoor Led Video Display P5.33 IP65 Waterproof

High Brightness Outdoor Led Video Display P5.33 IP65 Waterproof thumbnail-1
High Brightness Outdoor Led Video Display P5.33 IP65 Waterproof photo-1
US$ 4 - 5 MOQ: 1 Kilogram
Key Specifications
Get Latest Price
Brand Name:
NFCase
Place of Origin:
China
Model Number:
AIA-1
Contact Supplier Request Quote Chat Now
Shenzhen Eastar Electronic Co., Ltd,
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name NFCase
Place of Origin China
Model Number AIA-1
Delivery Time:3-5 days
Certification:CE,FCC,MSDS


High Brightness Outdoor Led Video Display P5.33 IP65 Waterproof

Feature:

SMD3535 for outdoor usage, high brightness with bigger viewing angle;

IP65 waterproof, front and rear side;

Controlling box is replaceable, press the side button to take it out and insert a new one quickly;

Aluminum case to ensure fast heat elimination, no fans and no noise;

Simple but unique cabinet\'s design, light & thin; side lock system with quick and seamless installation.


Specification:

Model: RK53S RK6S RK8S RK10S RK10S(DIP)
Pixel Pitch (mm): 5.33 6.67 8 10 10
Physical Density (dot/m2): 35,156 22,500 15,625 10,000 10,000
LED Configuration: 1R1G1B 1R1G1B 1R1G1B 1R1G1B 1R1G1B
LED Type: SMD3030 SMD3535 SMD3535 SMD3535 DIP346
Module Size (mm x mm): 320*320 320*320 320*320 320*320 320*320
Module Resolution (PX x PX): 60*60 48*48 40*40 32*32 32*32
Module Power Consumption (W): 70 70 70 70 70
Drive Mode: Constant Current Drive Constant Current Drive Constant Current Drive Constant Current Drive Constant Current Drive
Horizontal Viewing Angle (Deg): 140 140 140 140 140
Vertical Viewing Angle (Deg): 140 140 140 140 140
Brightness (cd/m2): 4,500 4,500 4,500 5,300 8,000
Grey Scale: 14 14 14 14 14
Refresh Rate (Hz): ＞960 ＞960 ＞960 ＞960 ＞960
Cabinet Resolution (PX x PX): 120*120 96*96 80*80 64*64 64*64
Cabinet Max Power Consumption (W): 300 300 300 300 300
Cabinet Average Power Consumption (W): 120 120 120 120 120
Cabinet Size (mm x mm): 640*640 640*640 640*640 640*640 640*640
Cabinet Weight (Kg): 18 16.5 17 17 17
Cabinet Thickness (mm): 89 88 88 88 88
Cabinet Material: Aluminum Aluminum Aluminum Aluminum Aluminum
Color (M): >16.7 >16.7 >16.7 >16.7 >16.7
Input Voltage (V): 110-240VAC 110-240VAC 110-240VAC 110-240VAC 110-240VAC
Refresh Frame Frequency (Hz): 50/60 50/60 50/60 50/60 50/60
Protection Level: IP65 IP65 IP65 IP65 IP65
Working Environment: outdoor outdoor outdoor outdoor outdoor
Working Temperature (℃): \"-20°- +40° \"-20°- +40° \"-20°- +40° \"-20°- +40° \"-20°- +40°
Operation humidity (RH): 10%-90% 10%-90% 10%-90% 10%-90% 10%-90%
Certificates: TUV-EMC,CE TUV-EMC,CE TUV-EMC,CE TUV-EMC,CE TUV-EMC,CE


High refresh rate:
Delicate and smooth picture at high speed shutter, without ripple or flicker; vivid video to restore true picture;
Visual fresh rate over 3000hz, high performance led display;
High refresh rate with stable video play and less flash;
Low fresh rate results in horizontal stripes with camera, and also damage to eyes for too much flash lights.

High grey scale:
Rich color leave with low b
