Help CenterCrystal Ashtray Surface Laser Engraving Machine
Related Products
-
CO2 Laser Engraver for Marble/Granite/TileNegotiableMOQ: 1 Piece -
IC Surface CO2 Laser Marking MachineNegotiableMOQ: 1 Piece
-
PVC Inflatable Cushion CO2 Laser Cutting MachineNegotiableMOQ: 1 Piece
-
Paper and Paperboard Laser Cutter Engraver MachineNegotiableMOQ: 1 Piece
-
LED Light Guide Panel Laser Cutting MachineNegotiableMOQ: 1 Piece
Hot Keywords:crystal ashtray engraving machine,crystal ashtray laser engraving,crystal ashtray laser engraver,crystal ashtray engraver machine,crystal engraving machine,crystal ashtray laser engraving,crystal ashtray laser engraver
Product Feature
1. Working area is 700*400 (mm)
2. Standard collocation is 50W DC and sealed glass tube. Also can choose RF metal tube 30W USA Laser tube.
3. Adopts double side working table, (one side is honeycomb working table, the other side is strip working table). Suitable for processing various non-metal material such as acrylic, wood, plastic, plywood, etc.
4. Adopt automatically up & down working table, which is suitable to deal with different thickness material.
5. Could add-install rotary system on the machine to realize engrave on cylinder material.
6. Could add-install the auto focus system on the machine to realize auto focus on your material.
7. Providing Golden Laser original software with strong supporting function. Can be compatible with AI, BMP, PLT, DXF, DST etc. Format file.
8. Offline stepping or servo moving control system and synchro belt moving.
Application Field
Applicable Materials: Wood, Plywood, Bamboo, MDF, Balsa, Veneer Inlays, Acrylic, Acryl, PMMA, Perspex, Plexiglas, Plexiglass, Organic Glass, Rubber Sheet, Plastic, Industrial Plastics (PP, PE, PET, PVC, ABS, PA, PS, PC, etc. ), Paper, Corrugated Paper, Cardboard, Pressboard, Paperboard, Chipboard, etc.
Applicable Industries: Advertising Industry, Advertising Signs, Plastic Industry, Printing & Packing Industry, LED LGP Panel, Gifts & Crafts, Promotional Items, Plaques, Trophies, Awards, Bangles, Badges, Tags, Decorations, Souvenirs, Precise Ornaments, Model Toys, Architectural Models, Furniture Interiors, Wood Floors, etc.
|
Main Technical Parameter |
|
|
Laser type |
Hermetic and detached CO2laser tube |
|
Laser power |
50W |
|
Cutting area |
700mm×400mm |
|
No-load max speed |
0-24000mm/min |
|
Cutting table |
Honeycomb strip panel double-face working table |
|
Repeating location |
±0.1mm |
|
Automatic up & down distance |
0-150mm |
|
Moving system |
5 inch LCD display, Offline stepping motor system |
|
Cooling system |
Water cooling and protection system |
|
Power supply |
220V±5%/50Hz |
|
Format support |
AI,BMP,PLT,DXF,DST etc |
|
Standard collocation |
Mini air compressor, 550W down exhaust fan |
|
Select collocation |
CO2 RF metal laser tube,Rotary engraving system, red cross positioning system,constant temperature water chiller,servo system |
GoldenLaser Serve You the Leading Industrial Laser Solutions and Best Service System
Pre-sale service :
1 Technical consultation
According to your needs ,we will provide consultations about any professinal technology and the price for you ,also, we will post you the ralated samples and product information, or reply quikly for the any problem you concerned timely, for instance ,the application of distinction about processing technology in diffrent materials, the relation between processing time and floriated color, etc.
2 inspection and reception
We welcome you inspect our company anytime ,and provide you with any conveniences.
Medium-sales service:
1 Whether you are overseas customers as well as domestic customers, our old customer or our new friends , your contract amount is large or small, we will all give the same treatment with honest, fair, enthusiasm and carefully
2 We guarantee that we will enforce the provisions of the contract terms puntually, quality and quantity, and provide value-added services, such as the installation, training, etc.
After-sales service:
We established the global after-sales service information processing system, for tracking customer 24 hours .
1 Since the date of purchase,you can lifely enjoy software upgrades freely.
2 Since the date of purchase ,you can come to our company anytime to attend technical trainning courses.
3 In domestic maintenance service, within 300 kilometers,we promise to repair and service door to door in 24 hours, otherwise, in 72 hours . we will give the foreign clients reply in 10 hours and make maintenace services in 72 hours .
4 Global after-sales service hotline :400-812-9977
