Steel Wire Tensile Testing Machine

Steel Wire Tensile Testing Machine thumbnail-1
Steel Wire Tensile Testing Machine thumbnail-2
Steel Wire Tensile Testing Machine thumbnail-3
Steel Wire Tensile Testing Machine photo-1
Steel Wire Tensile Testing Machine photo-2
Steel Wire Tensile Testing Machine photo-3
US$ 10000 - 30000 MOQ: 1 Kilogram
Key Specifications
Get Latest Price
Brand Name:
LIYI
Place of Origin:
China
Model Number:
LY-1075
Contact Supplier Request Quote Chat Now
Dongguan LIYI Environmental Technology Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name LIYI
Place of Origin China
Model Number LY-1075


Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: LIYI
  • Model Number: LYH-300D
  • Power: Hydraulic
  • Usage: Bending Testing Machine
  • Force Capacity: 300KN/600KN/1000KN/2000KN
  • Control: Computer control
  • Accuracy: ±1%

Packaging & Delivery

Packaging Details: each packed in wooden case
Delivery Detail: within 15 days after deposit

Specifications


Steel Wire Tensile Testing Machine
1.Factory supplier
2.Hydraulic control,huge force capacity
3.Tensile, compression test



Steel Wire Tensile Testing Machine





Structure Introduction:

1. Steel Wire Tensile Testing Machine is mainly used to execute the tension, compression, bending, shearing etc. test for metal materials. Attached simple accessories and devices, it can be used to achieve many kinds of mechanical performances.



2. The oil cylinder is at the bottom of the load frame, tension space is at the upside of the load frame, compression and bending space is between lower crosshead and working table. The lower crosshead is driven by motor through decelerator, chain transmission device and screw pair, so realize the adjustment of testing space.



3.  Steel Wire Tensile Testing Machine adopts Load cell measure load, use computer control & display load,





Main Parameters:

              Tester Model

LYH-300D

LYH-600D

LYH-1000D

LYH-2000D

Max load(kN)

300

600

1000

2000

Test range

6KN-300kN

12KN-600kN

20KN-1000kN

40KN-2000kN

Test force accuracy

±1%

Displacement resolution

0.01mm

Deformation test accuracy

±0.5%

Constant force/ displacement controlling accuracy

SV<10%FS, less than ±1.0% of SV

SV≥10%FS, less than ±0.5% of SV

Deformation rate control accuracy

Rate <0.05%FS, less than ±2.0% of SV

Rate ≥0.05%FS, less than ±0.5% of SV

Max drawing space

800mm

800mm

850mm

800mm

Max compressing space

700mm

700mm

700mm

700mm

Flat sample clamp thickness

0-15mm

0-15mm

0-40mm

0-60mm

Round sample clamp diameter

φ6-φ26mm

φ13-φ40mm

φ13-φ60mm

φ15-φ70mm

Bending test branch space

450 mm

Branch width

140mm

Branch diameter

30mm

Piston Stroke

250mm

Clamp method

Built-in Hydraulic clamp

Outer demension

Machine

990×600×2435mm

990×600×2453mm

1100×770×2490mm

1160×1100×

2600mm

Oil source

1100×700×950mm

Complete weight

2800kg

3000kg

4700kg

6500kg
