Light Steel Prefabricated House
Negotiable
MOQ: 200 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Dubung
Place of Origin:
China
Model Number:
PD-1
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Brand Name
Dubung
Place of Origin
China
Model Number
PD-1
Introduction:
It is a kind of light steel structure prefab house with the EPS color steel sandwich
panel, rock wool, PU for the insulation. It can maximize customer require and
satisfaction for the cost and quality. All the house parts are knock-down as flat
package before loading container. We can provide the service of installation,
supervision and training by extra. Regarding to the house details, please check as
follows:
House Size:
1) Length is free as your requirement
2) Width: single-span beam less than 12m
3) Height: single floor less than 4m, for two and three floors height less than 3.5m
4) Roof pitch: slope is 1:10~1:3
5) Floors: max is three storeies
House Body:
1) Door: outside door as SIP door, aluminium alloy door or security door. inside door
as SIP door, aluminium alloy door or Compound wooden door
2) Window: PVC material or aluminium alloy with window screen
3) Ground channel: U type, galvanized, thick is 0.8mm
4) Square column: painted, with color steel compression decorative parts
5) Wall beam: C type with paint
6) Roof beam: with paint
7) Purline: C type with paint
8) Compression decorative parts: made of 0.4mm thick color steel sheet
9) PVC ceiling or aluminium panel for bathroom and kitchen, mineral wool acoustic
panel for the other area
10) Wall board: EPS color steel sandwich panel ,rock wool, PU for the insulation
11) Roof board: EPS color steel sandwich panel ,rock wool, PU for the insulation
House Accessaries:
1) Elevation floor: design as client's detailed requirement
2) Watering system: custom made design and construction or as chinese national
standard
3) Wiring system: custom made design and construction or as chinese national
standard
4) Sanitary appliance: source china market for your needs
5) Furniture: source china market for your need
Design technical data:
1) Wind load:0.6KN/㎡
2) Roof dead load:0.35KN/㎡
3) Roof live load: 0.5KN/㎡
4).Earthquake intensity: 8 grade
5).Location temperature:-25ºC to 45ºC
Installation efficiency:
Four skilled labors can assemble 40 ㎡ house body in 8 hours.
Container transportation:
Every 40ft sea container may load 150-180 ㎡ house body stuff.
Project case:
Office of construction camps
It is a kind of light steel structure prefab house with the EPS color steel sandwich
panel, rock wool, PU for the insulation. It can maximize customer require and
satisfaction for the cost and quality. All the house parts are knock-down as flat
package before loading container. We can provide the service of installation,
supervision and training by extra. Regarding to the house details, please check as
follows:
House Size:
1) Length is free as your requirement
2) Width: single-span beam less than 12m
3) Height: single floor less than 4m, for two and three floors height less than 3.5m
4) Roof pitch: slope is 1:10~1:3
5) Floors: max is three storeies
House Body:
1) Door: outside door as SIP door, aluminium alloy door or security door. inside door
as SIP door, aluminium alloy door or Compound wooden door
2) Window: PVC material or aluminium alloy with window screen
3) Ground channel: U type, galvanized, thick is 0.8mm
4) Square column: painted, with color steel compression decorative parts
5) Wall beam: C type with paint
6) Roof beam: with paint
7) Purline: C type with paint
8) Compression decorative parts: made of 0.4mm thick color steel sheet
9) PVC ceiling or aluminium panel for bathroom and kitchen, mineral wool acoustic
panel for the other area
10) Wall board: EPS color steel sandwich panel ,rock wool, PU for the insulation
11) Roof board: EPS color steel sandwich panel ,rock wool, PU for the insulation
House Accessaries:
1) Elevation floor: design as client's detailed requirement
2) Watering system: custom made design and construction or as chinese national
standard
3) Wiring system: custom made design and construction or as chinese national
standard
4) Sanitary appliance: source china market for your needs
5) Furniture: source china market for your need
Design technical data:
1) Wind load:0.6KN/㎡
2) Roof dead load:0.35KN/㎡
3) Roof live load: 0.5KN/㎡
4).Earthquake intensity: 8 grade
5).Location temperature:-25ºC to 45ºC
Installation efficiency:
Four skilled labors can assemble 40 ㎡ house body in 8 hours.
Container transportation:
Every 40ft sea container may load 150-180 ㎡ house body stuff.
Project case:
Office of construction camps
