It is a kind of Mobile house with elevated floor. It can be knock-down as flat
package for the container transport. We can assemble and disassemble them
just by bolts. We can provide the service of installation, supervision and training
by extra. Regarding to the house details, please check as follows:
House Size:
1) Length is free as your requirement by modular 1224mm
2) Width: single span 5.05m
3) Height: less than 3.0m
4) Roof pitch: slope is 1:3
5) Floors: single floor
House Body:
1)Door: outside door as SIP door with aluminum alloy frame, aluminium
alloy door or security door,size:800mm*2000mm.Inside door as SIP door,
aluminium alloy door or Compound wooden door,size:750mm*2000mm
2) Window: color steel material or aluminium alloy with window screen
3) Post: H 56*40, material: Q235, modular pace: 1224mm. Galvanized
4) Ground channel: Z 50X60X30mm, material: Q235. Painted
5) Roof beam: The trusses are composed of 353 steel and 20X20mm steel,
Galvanized
6) Compression decorative parts: made of 0.4mm thick color steel sheet
7) Wall board: 50mm thick EPS color steel sandwich panel for the insulation
8) Roof panel: 60mm thick EPS color steel sandwich panel for the insulation
House Accessaries:
1) Ceiling board: Mineral wool, aluminium alloy, PVC and so on
2) Watering system: custom made design and construction or as chinese
national standard
3) Wiring system: custom made design and construction or as chinese
national standard
4) Sanitary appliance: source china market for your needs
5) Furniture: source china market for your needs
6) Elevated floor: steel structure
Design technical data:
1) Wind load: 0.6KN/sqm
2) Bearing load: 0.5KN/sqm
3) Earthquake intensity: 7 grade
4) Location temperature:-15ºC to 45ºC
Installation efficiency:
Four skilled labor can assemble 120 sqm house body in 8 hours.
Container transportment:
Every 40ft sea container may load 300 Sqm house body stuff.
package for the container transport. We can assemble and disassemble them
just by bolts. We can provide the service of installation, supervision and training
by extra. Regarding to the house details, please check as follows:
House Size:
1) Length is free as your requirement by modular 1224mm
2) Width: single span 5.05m
3) Height: less than 3.0m
4) Roof pitch: slope is 1:3
5) Floors: single floor
House Body:
1)Door: outside door as SIP door with aluminum alloy frame, aluminium
alloy door or security door,size:800mm*2000mm.Inside door as SIP door,
aluminium alloy door or Compound wooden door,size:750mm*2000mm
2) Window: color steel material or aluminium alloy with window screen
3) Post: H 56*40, material: Q235, modular pace: 1224mm. Galvanized
4) Ground channel: Z 50X60X30mm, material: Q235. Painted
5) Roof beam: The trusses are composed of 353 steel and 20X20mm steel,
Galvanized
6) Compression decorative parts: made of 0.4mm thick color steel sheet
7) Wall board: 50mm thick EPS color steel sandwich panel for the insulation
8) Roof panel: 60mm thick EPS color steel sandwich panel for the insulation
House Accessaries:
1) Ceiling board: Mineral wool, aluminium alloy, PVC and so on
2) Watering system: custom made design and construction or as chinese
national standard
3) Wiring system: custom made design and construction or as chinese
national standard
4) Sanitary appliance: source china market for your needs
5) Furniture: source china market for your needs
6) Elevated floor: steel structure
Design technical data:
1) Wind load: 0.6KN/sqm
2) Bearing load: 0.5KN/sqm
3) Earthquake intensity: 7 grade
4) Location temperature:-15ºC to 45ºC
Installation efficiency:
Four skilled labor can assemble 120 sqm house body in 8 hours.
Container transportment:
Every 40ft sea container may load 300 Sqm house body stuff.
