Help CenterFully Automatic Paper Bag Making Machine for Production Chemical , Food , Tea Bags
Related Products
-
Lime Bags Automatic Paper Bag Making Machine , Machines for Making Paper BagsNegotiableMOQ: 1 Set -
Full Automatic Cement or Chemicals Paper Bag Making Machines / Machinery / Production LineNegotiableMOQ: 1 Set
-
Customized Automatic Bottom-pasting Paper Bag Making Machine With Accelerate MotorNegotiableMOQ: 1 Set
-
Glued Bottom Automatic Paper Bag Making Machine / Paper Bags Manufacturing MachineryNegotiableMOQ: 1 Piece
-
Fully Automatic Sheet Feeding Paper Bag Making Machine With Automatic FeederNegotiableMOQ: 1 Set
Certification:CE
4-Colour Printing Automatic Glued Valve Sacks Making Machine for Cement
ZT9804 Tuber Machine
Operating condition
Working hour |
22 hours/day |
Design temperature |
0~40℃ |
Design humidity |
MAX. 95% |
Number required |
1 unit |
Model name |
ZT9804 |
Performance
|
130~150 tubes/min(Depends on paper quality, number of ply and operators’ skill.) |
Tube length |
670~1035 mm |
Tube width |
420~600 mm |
Space between tape steps |
20 mm |
Tube Cut Length |
670~1035mm |
Number of ply |
2~4 paper + 1 PP/PE(Please specify if you need paper bag with PP film) |
Diameter of print roller |
ø144～ø314 mm |
Printing width |
1300 mm(MAX) |
Paper reel width |
860~1260 mm |
Paper reel diameter |
Max. 1, 300 mm |
Air consumption |
1,100L/min |
Main drive motor |
30kw |
Size of whole set |
34.3m×2.4m×2.7m( L×W×H) |
Total weight |
30 T |
Composing of the production line
ZT9804 Tuber Machine
Name |
Quantity |
4-color printing machine |
1 |
Paper reel stands |
1 |
Paper web guider |
1 |
Automatic paper rectifier |
1 |
Auxiliary paper driver |
1 |
Perforation machine |
1 |
Latitudinal gluing machine |
1 |
Longitude gluing machine |
1 |
Tubes forming unit |
1 |
Driving tearing-off |
1 |
Delivery & counting line |
1 |
Electric control system |
1 (Schneider, German) |
Air compressor |
1 |
HD4916B Bottomer Machine
(bottomer with strength sheet pasting unit)
Operating condition
Working hour |
22 hours/day |
Design temperature |
0~40℃ |
Design humidity |
MAX. 95% |
Number required |
1 unit |
Model name |
HD4916B |
Performance
Max Speed |
110 bags/min(Depends on paper quality, number of ply and operators’ skill.) |
Bag length |
520~880mm |
Bag width |
420~600 mm |
Bottom width |
90~160mm |
Bottom open width |
200~440mm |
Distance between bottom centers |
420~780mm |
Valve sheet length |
100~300mm(adjustable) |
Valve sheet width |
120~240mm(adjustable) |
Main drive motor |
33kw |
Total weight |
25T |
Size of whole set |
23.5m×1.8m×1.8m ( L×W×H) |
Valve sheet reel diameter |
Max.1,300mm |
Number Patch Length |
(2~4)layers＋1PP film |
Composing of the production line
HD4916B Bottomer Machine
(bottomer with strength sheet pasting unit)
Name |
Quantity |
High speed feeder machine |
