Fully Automatic Sheet Feeding Paper Bag Making Machine With Automatic Feeder

Working hour

22 hours/day

Design temperature

0~40℃

Design humidity

MAX. 95%

Number required

1 unit

Model name

ZT9804


Speed

130~150 tubes/min(Depends on paper quality, number of ply and operators’ skill.)

Tube length

670~1035 mm

Tube width

420~600 mm

Space between tape steps

20 mm

Tube Cut Length

670~1035mm

Number of ply

2~4 paper + 1 PP/PE(Please specify if you need paper bag with PP film)

Diameter of print roller

ø144～ø314 mm

Printing width

1300 mm(MAX)

Paper reel width

860~1260 mm

Paper reel diameter

Max. 1, 300 mm

Air consumption

1,100L/min

Main drive motor

30kw

Size of whole set

34.3m×2.4m×2.7m( L×W×H)

Total weight

30 T

Name

Quantity

4-color printing machine

1

Paper reel stands

1

Paper web guider

1

Automatic paper rectifier

1

Auxiliary paper driver

1

Perforation machine

1

Latitudinal gluing machine

1

Longitude gluing machine

1

Tubes forming unit

1

Driving tearing-off

1

Delivery & counting line

1

Electric control system

1 (Schneider, German)

Air compressor

1

Working hour

22 hours/day

Design temperature

0~40℃

Design humidity

MAX. 95%

Number required

1 unit

Model name

HD4913

Speed

80~130 bags/min(Depends on paper quality, number of ply and operators’ skill.)

Bag length

520~880mm

Bag width

420~600 mm

Bottom width

90~130mm

Bottom open width

200~380mm

Distance between bottom centers

420~780mm

Valve sheet length

100~250mm

Valve sheet width

120~170mm

Main drive motor

33kw

Total weight

22.7T

Size of whole set

21.3m×2.3.m×1.8m ( L×W×H)

Valve sheet reel diameter

Max.1,300mm

Name

Quantity

High speed feeder machine

1

Perforation machine

1

Tube opening unit

1

Automatic gluing machine

1

Scrip sealing machine
