The specification of Solid sheet
1) Max Width:2100mm
2) thickness:1.4-12mm
3)Color:clear,blue,green,yellow,brown,opal
4) Fire retardant
Technical features:
1) Impact strength: 850J/m. The impact resistance of polycarbonate solid sheet is about 200 times of comman glass, 20 times of acrylic sheets.
2) Light weight:About 1/2 times of glass .
2) Light transmission(clear color)80%--90% for different thickness
2) Light transmission: 80%-92% for different thickness of clear color
3) Specific gravity: 1.2 g/cm3
4) Coefficient of thermal expansion: 0.065 mm/m℃
5) Service temperature range: -40℃to 120℃
6) Heat conductivity: 2.3-3.9 W/m2 oC
7) Tensile strength: >60N/mm2
8) Flexural strength: 100N/mm2
9) Modulus of elasticity: 2,400mPa
10) Tensile street at break: >65mPa
11) Elongation at break: >100%
12) Specific heat: 1.16J/kgk
13) Heat deflection temperature: 140℃
14) Soundproof index: 4mmthickness--27dB, 5mm--28dB, 6mm--29dB, 8mm--31dB, 10mm-32dB 12mm--34
