Certification:CE,FCC,MSDS
Multiline Powder stick Packing Machine
I.: How to choose right machine?
Please tell us following points to choose a right model packing machine:
1. What product will you pack?
2. How many gram and volume in each bag?
3. What bag shape you want to get?
4. What is bag width and bag length?
5. What bag material do you want to use?
II.: Specifications:
|
Packaging type |
Plastic stick shape/ back side sealing |
|
Driven Type |
pneumatic |
|
Measurement accuracy |
<= +- 1% |
|
Lanes quantity |
From 2 to 6 according the film width; |
|
Machine made of |
SUS 304 (for parts contacted material) |
|
Packaging material |
Laminated roll film |
|
Electric voltage |
380V / 3 phases / 50HZ |
|
Measurement device |
Multi auger controlled by servo motor |
|
Machine size(estimated) |
According to the detailed design. |
|
Date coding |
Ribbon printer(for chosen) |
III.: Description:
1. Sealing type: back sealing packing method.
2. Operation: packing running data and adjustment are directly displayed on the display. The user can directly operate it on the displayer.
3. Funcction: making bag, metering, filling, sealing, cutting, counting and printing batch number.
4. Body material: 304 stainless steel.
5. Filling type: measurement auger controlled by servo motor.
6. This machine can finish measuring, pulling, feeding, forming, cutting automatically.
7. Chinese-English operating screen display, easy operation and maintenance.
8. Mitsubishi PLC control system insure steady working conditions, and available to adjust any parameter without stopping the machine.
9. Adopt step motor to pull film, more accurate.
10. Independent temperature control system, precision±1 degree.
11. Independent control of horizontal / longitudinal temperature, to ensure a good fit of various kinds of complex film.
12. Automatic alarm protects system, to save the waste into minimum limited.
IV.: Applications:
|
Applicable product |
powder, Like coffee powder, milk powder, icing sugar powder and so on. |
|
Applicable field |
Food, daily consumption, medicine, chemicals… |
V.: Information we need:
To make an exact quotation for the granule products, it would be better if you could provide us information with following:
1. What kind of product you want to pack?
2. How many grams in one bag?
4. What is the bag size?
5. What kind of sealing form/bag shape?
6. Special requirement details are highly appreciated.
VI.: After-sales service:
1. one-year guarantee for the quality
2. Lifetime free service, we will replace the damaged accessory (except easy damaged parts) within the expiry date, but customer should bear the courier fee.
3. 24-hour online service.
