1080P HDMI 16Channel CIF H.264 CCTV DVR
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
IQVIEW
Place of Origin:
China
Model Number:
DVR9116
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
4Channel H.264 CCTV DVR With 3G DVR9004BVNegotiableMOQ: 10 Pieces -
4Channel 3G CCTV H.264 DVR DVR9004VNegotiableMOQ: 10 Pieces
-
8Channel H.264 CCTV DVR With 3G DVR9008BVNegotiableMOQ: 10 Pieces
-
8Channel 3G H.264 CCTV DVR DVR9008VNegotiableMOQ: 5 Pieces
-
16Channel 3G CCTV H.264 DVR DVR9216GVNegotiableMOQ: 10 Pieces
Brand Name
IQVIEW
Place of Origin
China
Model Number
DVR9116
Features
Support CVBS,VGA and HDMI output,support high definition 1080P realtime display
Mobile Phone view based on Symbian, Windows Mobile, iPhone, Blackberry & Android
HEXAPLEX operation – Record, Live view, Playback, Backup, Network Control & Mobile Phone Monitoring
Support digital zoom,support playback control bar and to playback the recorded video of any time
Support network remote monitoring,remote settings and management,remote updating
Specifications
| Model NO. | DVR9116 | |
| Video Compression | H.264 | |
| Video System | NTSC/PAL | |
| Operation System | Linux(embedded) | |
| Video-input /output | 16CH input /1CH output(BNC) | |
| Audio input /output | 4CH input /1CH output(RCA) | |
| Display | Resolution |
PAL:720×576@25fps(each ch,Frame) NTSC:720×480@30fps(each ch,Frame) |
| Feature | single/ Quad/Nine/Sixteen/S.E.Q. | |
|
Record (only record) |
Resolution |
PAL :360×288(CIF) NTSC:360×240(CIF) |
| Speed |
PAL:(each ch,Frame) CIF:25fps NTSC:(each ch,Frame) CIF:30fps |
|
| Recording Mode | Continuous/Manual/Motion detect /Sensor/Alarm recording | |
| Playback Channel | 1/4/9/16ch | |
|
Playback speed (Simultaneously 16CH Record ) |
PAL:(each ch,Frame) CIF:25fps NTSC:(each ch,Frame) CIF:30fps |
|
| Sensor & Alarm I/O |
8ch sensor input 1 channel alarm out |
|
| Network | Lan, DHCP, Dynamic IP and DDNS | |
| HDD interface | 1 SATA HDDs, up to 2TB | |
| Multiplex Operation | live display, record, playback, backup and network | |
| USB | 2xUSB(for mouse and backup/upgrade) | |
| PTZ Control | Built in RS485, support Pelco-P & Pelco-D | |
| Mobile Surveillance |
Support Mobile Phones based on Windows mobile, Symbian, iPhone, Blackberry and Android operation system |
|
| VGA | 800*600,1024*768,1280*1024,1440*900,1920*1080 | |
| HDMI | 1080P | |
| Power Supply | DC 12V 2A | |
| Dimension(wxDxH) | 300X227X53mm |
