1080P HDMI 4/8CH 960H H.264 CCTV DVR

1080P HDMI 4/8CH 960H H.264 CCTV DVR thumbnail-1
1080P HDMI 4/8CH 960H H.264 CCTV DVR thumbnail-2
1080P HDMI 4/8CH 960H H.264 CCTV DVR thumbnail-3
1080P HDMI 4/8CH 960H H.264 CCTV DVR photo-1
1080P HDMI 4/8CH 960H H.264 CCTV DVR photo-2
1080P HDMI 4/8CH 960H H.264 CCTV DVR photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
IQVIEW
Place of Origin:
China
Model Number:
DVR9704,DVR9708
Contact Supplier Request Quote Chat Now
Fuzhou IQVIEW CCTV Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name IQVIEW
Place of Origin China
Model Number DVR9704,DVR9708

Features

Support 960H display/recording resolution 960*576,better than D1 resolution
Support CVBS,VGA and HDMI output,support high definition 1080P realtime display
Mobile Phone view based on Symbian, Windows Mobile, iPhone, Blackberry & Android
HEXAPLEX operation – Record, Live view, Playback, Backup, Network Control & Mobile Phone Monitoring
Support digital zoom,support playback control bar and to playback the recorded video of any time
Support network remote monitoring,remote settings and management,remote updating

Specifications

Model NO. DVR9704 DVR9708
Video Compression H.264
Video System NTSC/PAL
Operation System Linux(embedded)
Video-input /output 4CH input /1CH output(BNC) 8CH input /1CH output(BNC)
Audio input /output 4CH input /1CH output(RCA)
Display Resolution PAL:960×576@25fps(each ch,Frame) NTSC:960×480@30fps(each ch,Frame)
Feature single/ Quad/S.E.Q. single/ Quad/Nine/S.E.Q.
Record(only record) Resolution PAL :D1 mode 360×288(CIF),720x288(HD1),720x576(D1)
960H mode 480×288(WCIF),960×288(WHD1),960×576(WD1)
NTSC:D1 mode 360×240(CIF),720x240(HD1),720x480(D1)
960H mode 480×240(WCIF),960×240(WHD1),960×480(WD1)
Speed PAL: (each ch,Frame)
D1mode/960Hmode:25fps
NTSC:(each ch,Frame)
D1mode/960Hmode:30fps 		PAL: (each ch,Frame)
CIF/HD1/D1:25fps,WCIF:25fps,WHD1/ WD1:9fps

NTSC: (each ch,Frame)
CIF/HD1/D1:30fps,WCIF:30fps,WHD1/ WD1:11fps
Recording Mode Continuous/Manual/Motion detect /Sensor/Alarm recording
Playback Channel 1/4ch 1/4/9ch
Playback speed
(Simultaneously Record ) 		PAL: (each ch,Frame)
D1mode/960Hmode:25fps
NTSC:(each ch,Frame)
D1mode/960Hmode:30fps 		PAL: (each ch,Frame)
CIF/HD1/D1:25fps(1CH-4CH ),CIF /HD1/D1 :12fps(8CH )
WCIF:25fps,WHD1/ WD1:9fps
NTSC: (each ch,Frame)
CIF/HD1/D1 :30fps(1CH-4CH ),CIF /HD1/D1:15fps(8CH ) ;
WCIF:30fps,WHD1/ WD1:11fps
Sensor & Alarm I/O 4ch sensor input,1 channel alarm out 8ch sensor input,1 channel alarm out
Network Lan, DHCP, Dynamic IP and DDNS
HDD interface 1SATA HDDs, up to 2TB
Multiplex Operation live display, record, playback, backup and network
USB 2xUSB(for mouse and backup/upgrade)
PTZ Control Built in RS485, support Pelco-P & Pelco-D
Mobile Surveillance Support Mobile Phones based on Windows mobile, Symbian, iPhone, Blackberry and Android operation system
VGA 800*600,1024*768,1280*1024,1440*900,1920*1080
HDMI 1080P
Power Supply DC 12V 2A
Dimension(wxDxH) 300X227X53mm
