HDMI extend HDMIV1.3b by cat5E/6(60m)

HDMI extend HDMIV1.3b by cat5E/6

The HDMICAT60RX&TX Extender use double cat-5E or cat-6(recommended) cables up to 60 metres instead of HDMI cable to transmit high definition signal, for cutting down cost. Long distance transmission of high definition is very difficult because HDMI cable is very expensive and infrequent. The Extender is designed to supply for long distance transmission of high definition signal.

Function:

         Perfect compatibility for various PS3/Blue-Ray /HD-DVD/ DVD/LCD-TV.

         It applies 2pcs LAN cable (with TIA/EIA568B connect standard) to instead of 1pcs HDMI cable to transmit HDMI signal.

These devices apply in home decorating, project show, TV education environment which need the HDMI signal transfer via cover-up or need transmit for long distance.

The special benefit:

1.         Long-length HDMI cable is expensive and can not be purchased unless custom-tailor.

HDMI length and connector is solid after production. Users cannot change its Length. Oppositely, CAT6/CAT7 cable can be easy got and easy to change length or change connector.

2.         HDMI cable is thick, it cannot be installed cover-up. Oppositely, CAT6/CAT7 cable can be installed conveniently into the wall.

         It can up support HDMI1.3v signal (10.2Gbps/deep color 36bit/xv-YCC/1080p24fs/dts-HD) for 60m transmit via CAT7 LAN cable.

         It can up support HDMI1.2v signal (5.1Gbps/24bit full-HD 1080p24fs/dts/AC3/LPCM) for 60m transmit via CAT6 LAN cable.

         It has a switch to select base on if you apply CAT7 (or CAT6) wires.

         Need 5v power adapter in HDMICAT_RX.

SPECIFICATIONS:                         HDMICAT60RX&TX

Length of CAT-5E or CAT-6 cable between Rx and TX....Up to 60 metres

HDMI Input.....24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i

Support audio format input..DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

HDMI Output......24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i

Support audio format output....DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

Max ..5.1Gbps

Input Video signal .... 0.5~1.5Volts p-p

Output DDC signal 5Volts p-p (TTL)

Input/Output HDMI1.3 cable distance....≤20m AWG26 HDMI 1.3 standard cable

Max working current...600mA

Power adapter formatInput:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/0.8A

Operating Temperature range... (-15 to +55)

Operating Humidity range...5 to 90%RH (No Condensation)

Dimension (L x W x H)       .8.2×4.5×2.1cmRX/TX

Weight......0.505kg
