Double Color Injection Machine DKM110D Dakumar-m
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Place of Origin:
China
Model Number:
DKM110D
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Mix-Colour Injection Molding Machine DKM188D Dakumar-mNegotiableMOQ: 1 Set -
Double Color Injection Machine DKM138D Dakumar-mNegotiableMOQ: 1 Set
-
Variable Pump Injection Machine DKM188H Dakumar-mNegotiableMOQ: 1 Set
-
PET Injection Machine DKM380 Dakumar-mNegotiableMOQ: 1 Set
-
Servo Injection Machine DKM-SV50 Dakumar-mNegotiableMOQ: 1 Set
Place of Origin
China
Model Number
DKM110D
DKM110D Double Color Injection Machine
DKM110D PLATEN DIMENSION DKM110D dakumar Injection Molding Machine DKM110D Parameters A B Injection Unit Screw Diameter mm 34 24 L/D cm 3 I+II=215 Injection Weight(PET) g I+II=195 Injection Pressure Mpa 205 230 Screw Speed rpm 0-220 0-200 C
DKM110D Double Color Injection Machine
PLATEN DIMENSION
|
DKM110D
|
||||
| dakumar Injection Molding Machine DKM110D Parameters |
A
|
B
|
||
| Injection Unit | Screw Diameter | mm | 34 | 24 |
| L/D | cm3 | I+II=215 | ||
| Injection Weight(PET) | g | I+II=195 | ||
| Injection Pressure | Mpa | 205 | 230 | |
| Screw Speed | rpm | 0-220 | 0-200 | |
| Clamping Unit | Clamp Tonnage | KN | 1100 | |
| Toggle Stroke | mm | 330 | ||
| Space Between Tie-Bars | mm | 375x375 | ||
| Max. Mold Height | mm | 380 | ||
| Min. Mold Height | mm | 150 | ||
| Ejector Stroke | mm | 100 | ||
| Ejector Tonnage | KN | 33 | ||
| Ejector Number | Piece | 5 | ||
| Others | Max. Pump Pressure | Mpa | 16 | |
| Motor Power | KW | 11 | ||
| Heater Power | KW | I+II=11.2 | ||
| Machine Dimension | m | 4.2x2.2x1.7 | ||
| Machine Weight | ton | 4 | ||
| Oil Tank Capacity | L | 200 | ||
