CE Certified Automatic PP Spun Non Woven Fabric Manufacturing Mmachine 3200SS

CE Certified Automatic PP Spun Bond Non-Woven Machine (3200SS)

Basic Info.

Model NO.:1600S, 2400SS, 3200SMS,3200SS,1600SMS,

Automatic Grade:Automatic

Certification:CE, ISO9001: 2000, SGS

Condition:New

1600,2400,3200width:100ton-200tons

Export Markets:Global

Additional Info.

Packing:Wooden Package

Standard:1.6M, 2.4M, 3.2M, 4M etc.

Origin:Made in China

HS Code:8449009000

Production Capacity:100set/Year

Product Description

Environmental Protection Material Non-Woven Machine
Product Description
Spunbonded Non-woven Machine

PRODUCT DIRECTIONS:
This production line is filament polypropylene fiber spunbonded non-woven fabric equipment. Its raw material is polypropylene(PP), take the principle of spinning man-made fibres, duringpolymer filature, continuous filament is extended into fiber, during
Which is finished by mechanical hot pressing. The machine assembly we adopt is now advanced veneer
Integer slot air flow draw technology, the whole process from material feeding to cloth
Output is automatic controlshort production flow, high working efficiency. The non-woven fabric we produce has high strength, good softness, innocuity, acterium-proof, corrosion
Resistance, high-levek draw strength ans elongation rate. They are widely used for dress,
Decoration materials, medical sanitation materials, daily life products and in the industrial, agricultural fields. In addition,
This production line can produce non-woven fabrics of different color, differen
Grams, different lines according to ueses\'demand
Width: 1.6m, 2.4m, 3.2m, lines on non-woven fabric: Dots, cross lines, straigh lines.


Product Description
Double Beam Nonwoven fabric making machine

>> Major Features & Function:

(1). Material: PP chip
(2). Weight range: 10-200G/M2
(3). Fabric usage: Medical applicant, Mask etc.
(4). Absorb the advanced technology from abroad
(5). Reasonable design
(6). Superior performance, uniform web form
(7). Filament denier: Less or equal to 2.5 denier.

Spun laid process and technical flow chart:
Additive(recycling waste edge)---> Raw material -->Melting--> Filtering-->Measuring-->Spinning-->Cooling-->Stretching-->Web forming-->Calendaring-->Rounding-->Final products

Parts of spun bonded nonwoven fabric production line:
Screw extruder ---> Metering pump--->Monomer suction device--->Quenching air chamber--->Stretching device--->Calendar--->Tension device---> Rim charge auxiliary screw and recycling device ---> spinning beam --->Filter--->Winder and suction system

>> Major Technical Parameters

Specification1600 SS/S2400 SS/S3200 SS/S
Dies QuantitySS: 2 sets S: 1 set
Effective Width (mm)160024003200
Weight Proportion (G/M2)12-80
Rated Line Speed (m/min)SS: 200-300
S: 150
Production Capacity (T/Y)SS: 3000-3900SS: 4500-5850SS: 6000-7800
S: 1500-1950S: 2250-2925S: 3000-3900
Fiber Denier1.6-2.5 D
