Pressure Transmitter Sensor Oem Low Cost (SS304)

SS304 Series Piezoresistive-type Pressure Transmitter Application 1,Industrial process measurement and control 2,Hydraulic and pneumatic system equipment 3,Pressure calibration 4,Compressors, dispenser 5,Refrigerator, locomotive braking systems Features 1,wide measuring range 2,all stainless steel EBW structure 3,Reverse polarity protection and Limiting protection 4,Corrosion resistance Anti-radio interference Lightning resistance 5,High accuraty High stability High reliability 6,Safety explosion-proof Performance & Parameters Measuring Media: Liquid gas and steam compatible with 316L stainless steel Measuring Range: -0.1Mpa~0~10Mpa Output: 4~20 mADC; 0~10/20 mADC; 0/1~5/10 VDC; 1KHz~10KHz Power Supply: 15~30 VDC; 15~28 VDC; 15~28 VDC Transmission: Two-wire system; Three-wire system Overload Pressure: 1.5×FS pressure Pressure type: PSIG, Absolute Pressure, Sealing Pressure Accuracy: ±0.25%FS(typical); ±0.5%FS(max) Long-term Stability: ≤0.1%FS/year Temperature Range: Operating Temperature: -40~120°C Storage Temperature: -40~160°C Zero Temp Coefficient: ±0.03%FS/°C(≤100KPa); ±0.02%FS/°C(>100KPa) Full-scale Temp coefficient: ±0.03%FS/°C(≤100KPa); ±0.02%FS/°C(>100KPa) Load Resistance: R=(U -15)/0.02-Rd (U-supply voltage,Rd-cable internal resistance) Shell Material: Stainless Steel 1Cr8Ni9Ti Protection Class: IP65 Explosion-Proof Mark: ExiaⅡCT6
