Pressure Transmitter Transducer Oem Low Cost (SS300)

SS300 Series Miniature Piezoresistive Pressure Transmitter Application 1,Industrial process measurement and control 2,Hydraulic and pneumatic system equipment 3,Pressure calibration 4,Compressors, dispenser 5,Refrigerator, locomotive braking systems Features 1,wide measuring range 2,all stainless steel EBW structure 3,Reverse polarity protection and Limiting protection 4,Corrosion resistance Anti-radio interference Lightning resistance 5,High accuraty;High stability;High reliability Performance & Parameters Supply Voltage 12~36 VDC*** Pressure Range 0~35KPa~10MPa Output Signal 4~20 mADC*** Proof Pressure 1.5×FS pressure Burst Pressure 3×FS pressure Accuracy 0.25%*** Stability 0.2%Full Scale Compensated Temp -10~75°C Operating Temp -20~80°C Fatigue Life Machanical Configuration Pressure Port 1/4NPT(typical)*** Electrical Connection Direct wire *** Sealing Rating IP65 Housing Stainless Steel 316L Diaphragm Diffused silicon
