30W KSAP0301200250HE Switching Power Adapters with 12VDC 2.5A CB , CE,GS Safety Approval used for Mo

Name: 30W KSAP0301200250HE Switching Power Adapters with 12VDC 2.5A CB , CE,GS Safety Approval used for Mo
Price: Negotiable

FOB Price

Negotiable / Kilogram

1 Kilogram(Min.Order)

Supply Ability 0 Kilogram / Kilograms per Month
Payment Terms:T/T L/C D/P D/A
Delivery Detail:7 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

China

Model Number:

30W KSAP0301200250HE

Product Description

Delivery Time:35days
Certification:CE,GS

30W KSAP0301200250HE Switching Power Adapters with 12VDC 2.5A CB , CE,GS Safety Approval used for Mobile Devices UL 60950 approval

Brand Name:	•
Input:	•Input Voltage :90 to 264 VAC •Frequency : 47-50/60-63hz •Input current : 1A (Max) 100 /240VAC •Inrush current: 60A Max120VAC at max Load 60A Max240VAC at max Load •Leakage current:0.25 mA Max
Output:	•Over voltage protection •Over current protection at 110-200% of lo and Auto-recovery •Electronic short circuit protection •100 Vac~180Vac Efficiency≥83% •180 Vac~240Vac Efficiency≥85% •Measured at 25℃ •Environmental Operating •Operating temperature 0~45℃ free convection •Operating humidity 10-90% RH Non Condensing •Sea level Non-operating temperature -20~ 80℃
Safety standards:	•Information technology equipment •IEC/EN 60950-1, UL 60950-1, CSA C22.2 No. 60950-1-03
Certificates and approvals:	•CE,GS
EMI Emission:	•Radiation Test&Conduction Test:EN 55022 •Harmonic Test : EN 61000-3-2 •Flicker Test : EN 61000-3-3
EMS immunity:	•ESD Test:EN 61000-4-2 •RS Test:EN 61000-4-3 •EFT Test:EN 61000-4-4 •Surge Test:EN 61000-4-5 •CS Test:EN 61000-4-6 •DIP Test:EN 61000-4-11
Key Applications:	Key Features of KSAP0301200250HE •Light, extra slim, sleek, compact design •High power density •Extra safe design, have got their respective safety approvals •Completed protect function •complies with K.21 Enhance level(6KV surge) •Reliability level of MTBF 50K hours @ 25° C Key Applications of KSAP0301200250HE •It’s suitable for an extremely wide range of applications, including: •Mobile Devices •ADSL •PLC
Payment Details:	•Payment Terms: T/T,negotiable for OEMs
Main Export Markets:	• Eastern Europe • North America • Mid East/Africa • Central/South America • Asia • Western Europe • Australasia
