High Efficiency Plastic Pipe Extrusion Machine Line Dust-Free Cutting Mode

Delivery Time:40-50 working days after received your payment
Certification:SGS/CE/ISO

High Efficiency Plastic Pipe Extrusion Machine Dust-Free Cutting Mode , Pvc Pipe Production

Quick details:

1. High output,high efficiency

2. easy to operate

3. dust-free cutting mode

PVC pipe making machine has the following features:

1. Extrusion Equipment of  PVC pipe making machine :Single screw extruder takes the new and efficient BM Screw,and has the higher screw speed, yield and plasticizing capacity...nose or spiral-flow nose,with a uniform material,convenient adjustment to eliminate extrusion fusion line and so on.

2. Vacuum shaping devices of PVC pipe making machine :vacuum spray tank,spray cooling tank or efficient cooling tank, and all water contact parts made of stainless steel material.

3. Traction machine of PVC pipe making machine :two claw-type or rubber belt crawler tractor in order to adapt to different pipe production requirements.

4. Cutting machine of plastic pipe making machine :No dust rotating knife.

5. Stacking devices of PVC pipe making machine :automatic turn plate or roller-type stacking devices, small-diameter pipe can be configured duplex winder according to customer requirements duplex winder.

6. Electrical control system for a variety of options (eg: PLC automatic control system),good production speed,stability,and the  control system is simple and easy to operate.

Specifications:

SJZ51/105	Screw diameter	51/105mm
Machine barrel and screw material	38CrMoAlA nitriding treatment
Main motor power	18.5KW
Contactor and breaker	Schneider Electric or Siemens
Vacuum calibration  tank	Vacuum pump power	4*1KW
Water pump power	4KW×2units
Haul off(2 claws)	Motor power	4KW
Lift Cutter	Saw motor	2.2KW
blower	1.5KW
The range of cutting pipe diameter	Ф16-50mm
Stacker	Length	5,000mm

Competitive Advantage:

We will invite customers to check the machine before shipment. And if the customer requests us to guide installment and test running in his factory, we will send our engineer. And the customer should pay for engineer’s ticket, visa, room and board, $80 per day for one people as allowance.

We normally guarantee machine quality for one year to key components of the machines, if key components of machine are broken for technical reason, we will replace it with new one free. (The customer should return broken components).
