Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Engraving Machine > SGS / CE PE Pipe Winder Machine 30m/min With 16 to 110mm Pipe

SGS / CE PE Pipe Winder Machine 30m/min With 16 to 110mm Pipe

US$ 2 - 2 MOQ: 1 Piece

Key Specifications

Get Latest Price

Brand Name:

S&K

Place of Origin:

China

Model Number:

SPS-32

Contact Supplier Request Quote Chat Now

Zhangjiagang S&K Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name S&K

Place of Origin China

Model Number SPS-32

Delivery Time:10 working days
Certification:SGS/CE/ISO

SGS / CE PE Pipe Winder Machine 30m/min With 16 to 110mm Pipe

Quick detail:

1: Total Power:10-40N.M

2: Max Speed:30m/min

3: Coiler Pipe Diameter:from16 to 110mm

1. Features and application:

The machine is mainly used in Coiler and packing of aluminium—plastic compound pipe,cross—linking compound pipe and other plastic soft pipes. It adopts automatically winding. Adjusting winding speed and winding method.It has two disk for continuous winding. It adopts air—operated method. The wheel rib of the winding up wheel adopts air—operated opening and closing.It is equiped with a ray creel stand to automatically wind displacement. It reaches winding up orderly. The machine structure is compact.Its automatication is high,Its appearance is beautiful and its operation is convenient.

2. Operate process:

Switch-on the electrical source,calandria system working.switch-on winding plate electromagnetism clutch,plate A work.plate B does not work.When plate A is full,close electromagnetism clutch ,at that time plate A stop,open the plate B ,let plate B working ,

Plate A feeding ,the two plate cross-use,and made the whole machine continuity working.

Adopt advanced pneumatic priciple feeding ,switch-on the feeding button , electromagnetism working ,culinder working ,made the feeding action to come true.

3. Detailed technical parameters

Model	DPS-32 (Single)	SPS-32 (Double)	DPS-63(Single)	SPS-63 (Double)	DPS-110 (Single)
Inner diameter of coil	450-800 mm	450-800 mm	550-1500mm	550-1500mm	800-2000mm
Outer diameter of coil	1050-1400mm	1050-1400mm	1150-2100mm	1150-2100mm	1600-2800mm
Max Winding Speed	30m/min	30m/min	30m/min	30m/min	15m/min
Winding Width	300-500 mm	300-500 mm	300-500 mm	300-500 mm	Max700 mm
Pipes diameter	Ø16-32 mm	Ø16-32 mm	Ø20-63 mm	Ø20-63 mm	Ø75-110 mm
Air Pressure	0.6mpa	0.6mpa	0.6mpa	0.6mpa	0.6mpa
Moment Motor	10N.M	10N.M	25N.M	25N.M	YLJ132- 40N.M-4
Reduction Box	WPA100	WPA100	WPA120	WPA120	WPEA 70-120
Cylinder Model	SC 50×75	SC 50×75	SC 50×75	SC 50×75	SC 80×100
Clutch	M3-25A	M3-25A	M3-40A	M3-40A
winding displacement	GP40	GP40	GP40	GP40	GP50
Dimension	1800×1450×1500	2800×1700×1800	2300×1550×2200	3000×2800×2000	3600×2100×3300
Weight	600KG	800KG	800KG	1500KG	3000 kg
