Solar Power Inverter Controller All in One 1Kw / 2Kw / 3Kw / 4Kw / 5Kw / 6Kw With 12Vdc 24vdc 48vdc

Solar Power Inverter Controller All in one 1Kw / 2Kw / 3Kw / 4Kw / 5Kw / 6Kw with 12Vdc 24vdc 48vdc

Model: Solar Inverter Controller All in one Cosmos Star Series 1000W-6000W (1ph in/1ph out)

Solar Inverter Overview

1: Remote control & RS232 communication port

2: Working modes switches automatically– AC Grid bypass mode, inverter mode, AC Charging mode,

     solar charging mode

3: Inbuilt MPPT 20/30/40/50/60A, with DC Voltage 12/24/48VDC

4: LCD&LED Screen for option

Key Features:

1: Professional off grid solar system solution, which is a combination of big power inverter and solar controller
2: Working modes switches automatically– AC Grid bypass mode, inverter mode, AC Charging mode, solar charging mode
3: Pure sine wave output which matches wave form of AC grid no matter is on AC grid mode or inverter mode, workable on inductive load
4: Remote control & RS232 communication port
5: Power saver mode
6: Four stages smart charging, charging current adjusted automatically
7: DIP switch optional: Selectable charging voltage for various battery type
8: Manual control input&output breakers
9: AC Grid priority & battery priority working mode as selectable
10: AC grid mode: AC Bypass supplies load when AC is normal, battery invert AC supplies load when AC is off
11: Battery priority: battery invert supplies load when battery get full-charged; AC bypass supplies load when battery low and at the meantime battery get charged from solar controller. It transfers back to battery invert mode when battery get full charged. It makes full use of solar energy and saves electricity.
12: LCD&LED Screen for option
13: Inbuilt MPPT 20/30/40/50/60A, with DC Voltage 12/24/48VDC
