80mm Thermal Receipt Printer Auto Cutter Feature Print Speed 230mm/s WIFI Interface
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Total Employees:
101 - 200 People
Main Markets:
North America, South America, Eastern Europe
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
80mm Thermal Receipt Printer With Auto Cutter Serial+USB+LAN InterfaceNegotiableMOQ: 1 Unit -
58mm Thermal Printer Mechanism Seiko LTPJ245G CompatibleNegotiableMOQ: 100 Units
-
58mm Thermal Printer Mechanism Fujitsu FTP628MCL113 Head CompatibleUS$ 8 - 8MOQ: 100 Kilograms
-
2inch Thermal Printer Mechanism Seiko LTPJ245E Printing Unit CompatibleNegotiableMOQ: 100 Units
-
Thermal Printer Mechanism Seiko LTP1245 Head CompatibleNegotiableMOQ: 100 Units
The YCP-80WF thermal printer features:
WIFI router interface (Optional: USB+LAN+WIFI, Serial+USB, Seial+USB+LAN, LAN, Parallel)
80mm paper width and 24V voltage,
Auto cutter function (full/partial cut),
Fast print speed at 230mm/s,
Compatible ESC/POS command,
Printer head life: 160KM,
Cutter life: 1,500,000 cuts
Detailed specifications:
| Model | YCP-80WF | |
| Printing | Method | Direct Thermal Dot Line Printing |
| Printer Head | China | |
| Speed | 230mm/sec | |
| Resolution | 203DPI(8dot/mm) | |
| Width | 72mm(576 Dots/Line) | |
|
Character Per Line |
Font A(12x24) | 48 columns |
| Fond B(9x17) | 64 columns | |
| Paper | Type | Thermal Paper |
| Width | 50mm-82.5mm | |
| Thichness | 0.06mm-0.09mm | |
| Roll Diameter | Max 80mm | |
| Roll Core Inner Diameter | 12.5±0.5mm | |
| Auto Cutter | Life | 1,500,000 cuts |
| Method | Full/Partial Cut | |
| Reliability | TPH Life | 160km |
| Interface |
WIFI Interface, Adopt IEEE802.11b/g WIFI Standard |
|
| Frequency | 2.412-2.484GHZ | |
| Tranmission Distance | 100M/outside,50M/inside | |
| Barcode |
EAN-8,EAN-13,Code 39,Code 93,Code 128, ITF,UPC-A,Codabar |
|
| Language | Buyer language support | |
| Emulation | ESC/POS command | |
| Driver | WinXP,2000,2003,Linux,Win 7 32&64 bit | |
| Sensor |
Paper End Sensor, Black Mark Sensor, Cover Open Mark Sensor |
|
| Certification | CE,FCC,ISO9000,RoHS | |
| Warranty period | 24 months | |
| After sale service | 2% free spare parts with order | |
| Oem service | Yes,MOQ 100pcs. | |
| Dimension (cm) | 18(L)*15(W)*14(H) |
