15KVA / 20KVA 380V / 400V Online Uninterruptible Power Supply For CTP Plate Machines
Negotiable
MOQ: 1 Kilogram (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
UPSEN
Place of Origin:
China
Model Number:
Queen Star Series 6-20Kva
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Home / Office Pure Sinewave 3000VA High Frequency Online UPS Single PhaseNegotiableMOQ: 1 Piece -
Pure Sine Wave 1Kva - 20KVA High Frequency Online UPS for CTP Plate Machines 50Hz / 60HzNegotiableMOQ: 1 Piece
-
6KVA / 10KVA IGBT DSP Single Phase UPS Systems 220V / 230V / 240VACNegotiableMOQ: 1 Piece
-
Pure Sine Wave 3 Phase High Frequency Online UPS With SNMP / USB / RS-232 PortsNegotiableMOQ: 1 Piece
-
1Kva - 20Kva IGBT Dual Conversion HF Online UPS System 50Hz / 60HzNegotiableMOQ: 1 Kilogram
Brand Name
UPSEN
Place of Origin
China
Model Number
Queen Star Series 6-20Kva
Delivery Time:7-15 Days
Certification:CE, ISO, RoHS
Certification:CE, ISO, RoHS
15KVA / 20KVA 380V / 400V Online Uninterruptible Power Supply For CTP Plate Machines
Model: High Frequency Online UPS Queen Star Series 6-20 Kva (1ph in / 1ph out) (3ph in / 1ph out)
Key Features:
DSP Technology: The advanced DSP digital control technology enable UPS more stable performance. Environment Friendly: This UPS is eco-designed and manufactured to meet the China local pollution control requirement of Electronic Products, which means it will cause no harm to environment and human beings in normal usage. Active input power factor correction (PFC): Digitalized control of the PFC enable the UPS to keep input power factor above 0.99 to prevent possible electric grid pollution and meanwhile mostly save the cost. Widened range of input voltage and frequency: We intentionally widen the range of input factors to make sure the UPS can apply to various environment, which will effectively sustain the battery charging even in unstable power environment so that the service life of the UPS could be obviously prolonged. Zero power switch delay: When the utility power fails, UPS will automatically switch from AC mode to battery mode with no delay, which will ensures stable power supply of operating system. Adaptive Load Management: This technology allows the UPS to be set up at a fixed 50Hz or 60Hz output, while it also can intelligently monitors power usage and automatically sheds and reconnects loads in order to prevent generator overload. Sufficient Expansion Slots: The pre-allocated smart slots enable flexibility in choice of USB cards,AS400 cards, CMC monitoring cards, SNMP cards, RS485 cards and EMD environment monitoring cards. The load power factor is 0.8: it adapts the features of most current electric equipment and elevates the load-bearing capacity of the machines. Support the Generators: The wide range of input voltage and frequency can effectively separate the harmful electric wave produces by the generators and provide safe and reliable power supply. Large-screen LCDTechnical Specification
| Queen Star Series Q6K-20Kva | |||||||
| Model | Q6K | Q6KL | Q10K | Q10KL | 31Q10KL | 31Q15KL | 31Q20KL |
| Capacity | 6KVA/4800W | 10KVA/8000W | 15KVA/12KW | 20KVA/16KW | |||
| Input | Nominal Voltage | 220/230/240Vac | 380/400/415Vac | ||||
| Voltage Range | 176~276Vac (1P2W+G) | 304~478Vac (3P4W+G) | |||||
| Current | 31A (max) | 50A (max) | 50A (max) | 75A (max) | 100A (max) | ||
| Frequency | 46~54Hz/56~64Hz | ||||||
| Power Factor | ≥0.99 | ||||||
| Output | Voltage | 220/230/240± 2%Vac (1P2W+G) | |||||
| Frequency | 50/60Hz(adjustable) 50/60Hz± 5% (Line mode) 50/60Hz ± 0.05Hz ( Battery mode) |
||||||
| Current | 27.3A | 45A | 68A | 91A | |||
| Power Factor | 0.8lag | ||||||
| Waveform | Pure Sine Wave | ||||||
| Waveform Distortion | Line load ＜2% | Line load ＜3% | |||||
| Back-up Time | Full Load | ≥7′ | Depends on external batteries bank\'s Capacity | ≥5′ | Depends on external batteries bank\'s Capacity | ||
| Half Load | ≥20′ | ≥13′ | |||||
| Battery Nominal Voltage | 192/240Vdc | ||||||
| Transfer Time | 0ms | ||||||
| Overload Capacity | ＞105% 1min, ＞120% 30s transfer to bypass, shut down in 1min | ||||||
| Communication | SNMP,RS-232,USB+Intelligent Slot | ||||||
| Operating Environment | Temperature | 0C~40℃ | |||||
| Humidity | 15%~90% | ||||||
| Dimension | Width (mm) | 260 | 260 | 260 | 260 | 260 | |
| Depth (mm) | 560 | 533 | 560 | 533 |
