Remote Control Portable Welding Fume Extractor / Soldering Fumes Extractor Machine

Delivery Time:10 working days after received your payment
Certification:CE/ROHS/SGS

Remote Control Solder Fume Extractor 0.3micron 99.97% Filtering Efficiency


Specifications:


Model Number:	F6002D
Filters Quantity:	pre-filter 5pcs, middle filter 1pc, main filter 1pc
Voltage/Power:	110-220V, 200W
Systemic Flow:	2 x 150m3/h
Air Velocity:	2 x 11m/s
Filtering Efficiency:	0.3micron 99.97%
Length of Duct:	Dia.75mm x 1.4m
Noise:	Less than 60db
Dimensions(mm)	420x245x400
Net weight	13kgs


Description:

1.The fume extractor is for cleaning of both particles and gases.

2.The fume extractor is designed to filter the harmful substances, such as hydrocarbon and cyanide, during the process of soldering, tin dipping in the solder pot, laser marking and carving, printing, etc.

3. The fume extractor catches harmful smoke with freestanding ducts and adjustable air volume to significantly improve your working environment.

4. The fume extractor has a triple-filter system.
1) Pre-Filter: the large-size pad filter can filter large particles of dust
2) Middle Filter: it filters the bigger powders for prolonging the main filter\'s life.
3) Main Filter: it includes HEPA (high efficiency) filter and gas filter. The HEPA cleans the gas and powders filtering from the pre-filter and then carry them to the gas filter. which with the carbon and other chemical combination, filters off the deleterious substance and then outputs the clean air.

5. We have been selling a good quantity of our solder fume extractors to Germany, Israel, UK and a few other European countries. And we got quite good and positive feedback from them on the quality and performance of our products.

6. We make really effective fume extractors only. They are widely used in the process of soldering, laser marking & carving, printing, etc.


Features:

1.With the intelligent control panel and digital display, the operation becomes easy and simple. By pressing the button, you can freely adjust the air volume and set the working time,. you can achieve real-time monitoring on the working status.

2. Equipped with the remote control, the operator can control the machine from a distance.

3.With the truly sensitive and effective \"Filter Clogging Alarm System\". When the filter gets saturated and clogged, the machine will give sound and light alarms within 20 seconds. It notifies the operator to replace the filter in time, to guarantee a comfortable working environment.

4. The High-voltage and large-volume brushless motor, ensure low vibration, low noise, stable operation. and long life span.

5. Ducts can be bent or lengthened as desired and maintain their shape after adjustment, letting you place them exactly where suction is needed.

6. The machine surface is made of metal, more corrosion resistance and durable

7. With square absorbing hood which have bigger filter area

8. Provide trundle with brake, easy to move castors


Applications:

Waterun Technology Co.,Ltd manufacturing a variety of high quality air purification systems for filter the harmful substances. Our line of floor, bench top, mounted and portable units serve a variety of applications including welding, soldering, manufacturing, laboratory and pharmaceutical operations.Don’t despair if you don’t see your application listed below! Our modular product line can be configured in a number of different ways to address your specific requirements.Contact us today to find out the solutions!


1.	soldering fume extractor
2.	laser cutting, laser engraving and marking
3.	electronics Manufacturing
4.	welding, laser welding
5.	medical, moxibustion, moxa-moxibustion
6.	beauty fume extraction
7.	Pharma
