Home > Manufacturing & Processing Machinery > Machine Tools > CNC Machine Tools > Height Adjusting Automated Pipe Welding Positioner Turntable For Vessel Loading And Machining

Height Adjusting Automated Pipe Welding Positioner Turntable For Vessel Loading And Machining

Name: Height Adjusting Automated Pipe Welding Positioner Turntable For Vessel Loading And Machining
Brand: H-WELDING
SKU: 149895496
Availability: InStock

Wuxi H-welding Machinery Co.,ltd.

Height Adjusting Automated Pipe Welding Positioner Turntable For Vessel Loading And Machining thumbnail-1

Height Adjusting Automated Pipe Welding Positioner Turntable For Vessel Loading And Machining photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

H-WELDING

Place of Origin:

China

Model Number:

SHB05

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name H-WELDING

Place of Origin China

Model Number SHB05

Delivery Time:15 working days after received your payment
Certification:CE

Height Adjusting Automated Pipe Welding Positioners Turntable For Vessel Loading And Machining

Specifications:

Model	SHB10	SHB20	SHB40	SHB60	SHB80	SHB100
Rated loading kg	1000	2000	4000	6000	8000	100000
Max.Eccentricity distance mm	150	150	150	150	200	200
Max gravity center distance mm	350	350	350	350	400	400
Work-table dia.mm	900	1200	1400	1500	1600	1800
Flip Angle	0～135°	0～135°	0～120°	0～120°	0～120°	0～120°
Revolve speed rpm	0.12～1.2	0.05～0.5	0.05～0.5	0.05～0.5	0.05～0.5	0.05～0.5
Tilt speed rpm	0.29	0.25	0.2	0.2	0.15	0.15
Revote driving power kw	1.1	1.1	2.2	2.2	2.2	3
Tilting driving power kw	1.1	1.5	2.2	3	4	4
Out size	A mm	1500	1780	2140	2760	3000	33330
B mm	1210	1320	1500	1630	1850	2020
C mm	1670	1800	2160	2600	2850	3140
E mm	1100～1700 (p=150)	1245～1845 (p=150)	1350～1950 (p=150)	1630～2430 (p=200)	1790～2670 (p=220)	1970～2930 (p=240)
F mm	775	1035	1360	1320	1630	1800
Rotation speed VPD controller

Description:

This series roller-bed features is auxiliary equipment for automatic welding. By proper adjustment, it can make work-piece at optimum welding position, attaining purpose of reducing labor intensity, improving, welding speed, guaranteeing welding quality.

Applications:

Altitude height not more than 1000m; Air temperature should not be out of the range: 0℃ ～ 40℃; Air relative humidity: Maximum average relative humidity is 90% when day average temperature is not more than 25℃;

Competitive Advantage:

The equipment should be installed in the place without industry gas, steam, salt fog
