Fixed Vessel Fit Up Welding Manipulator 5 * 5m Automated Welding Machinery
Negotiable
/ Square Meter
1 Square Meter(Min.Order)
- 0 Square Meter / Square Meters per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Linkage Control Welding Column and Boom Light Duty Type For Welding Center
-
Motorized Rotation Welding Working Station Manipulator for Pipe / Tank Welding Equipment
-
Heavy Duty Welding Manipulators Column Boom For Pressure Vessel Welding
-
Weld Column And Boom Welding Manipulators 7 * 7m Stationary Type With Flux And Recycle Unit
-
Wind Tower Assembly And Fit Up Welding Turning Rolls / Turning Bed Rotator with PU Roller
-
80 Ton Full-Automatic VFD Control Pipe Welding Rotators For Cylinder Seam Welding
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | LH5050 |
Product Description
Certification:CE
Fixed Vessel Fit Up Welding Manipulator 5*5m Automated Welding And Movable With Trolley
Specifications:
1-trolley ,2-column revolve unit,3-column,4-flux feeding and recovery system ,5-guide saddle,6-elevating unit,7-boom,8-welding system
|
Technical parameter |
LHZ4040 |
LHZ5050 |
LHZ6060 |
LHZ7070 |
|
Elevating stroke mm |
4000 |
5000 |
6000 |
7000 |
|
Retracting stroke mm |
4000 |
5000 |
6000 |
7000 |
|
Elevating speed mm/min |
1000 |
|||
|
Retracting speed mm/min |
120-1200 |
|||
|
Minimum distance between boom and track surface mm |
1110 movable with revolve/950 stationary with revolve |
1180movable with revolve/1170 stationary with revolve |
||
|
Boom end maximum weight loading kg |
120 |
200 |
||
|
Column revolving |
Angle |
＋180o |
||
|
Speed rpm |
0.36rpm/or by manual |
|||
|
Trolley traveling speed mm/min |
1700 |
2500 |
||
|
Inner span of trolley rail mm |
1730 |
2000 |
Description:
The boom with strength ribs, boom and column adopt triangle type rail, with large loading capacity and stable running.Applications:
Boiler industry Petroleum PowerCompetitive Advantage:
Strict requirements on structures welding seam, for example welding seam height not less than welded plate thickness\'s 0.7 times, structure all adopt anneal stress relieved and sandblasting treatment.Contact Us
